Dc Drive 1/20-2hp 115/230v Nib Lathe Bicl Smc-00 Dc Motor Speed Controller

US $65.00

Belleville, Ontario, Canada
Jan 29th

Open on mobile:
QR code

SMC layout BICL | 1-613-438-1280 WWW.BEEL.CA SHIPPING PAYMENT TERMS WARRANTY SMC MANUAL CONTACT US AUCTION INCLUDES: 1x SMC-00 BICL DC MOTOR CONTROL (SMC-00) 1/20-1HP @115VAC (90VDC) 10A 1/20-2HP @230VAC (180VDC) 10A New In Box NO EXTRA HEATSINK NOR HP RESISTOR REQUIRED! SMC-00 The SMC is a cost efficient reliable control for PM and Shunt Wound DC Motors. Installations are easily made to a barrier type terminal strip and large trim pots facilitate field adjustments. The SMC Series is ideally suited for: drill presses, lathes, bandsaws, conveyors, packaging machines, printers, process equipment centrifuges, and pumps. Standard features include: Start-Stop Inhibit Circuit 5% speed regulation 50:1 Speed Range Dual Voltage 115/230 VAC MOV & Fuse Protection Compact Size: 4”H x 4”W x 2”D (107mm x 07mm x 52mm) < 1 lbs. Performance Specifications: Speed Reference Voltage max. + 10VDC Operating temperature 0- +45?C Storage tempature 0- +60?C Adjustments: Min speed: 0-80% of max. Max. speed: 33-120% of max. IR Comp:0-10% Torque limit: 10-200% Accel/Decel: 0.5 to 20 seconds Speed Control pot value 5K ohms Start/Stop switch: dry contract Speed Regulation: Better than 5% of base speed (armature feedback; 1% Tacho Feedback*) *(Specify Model SMC-OT) CONTROLLER WIRING: CONTROLLER DIAGRAM: ELECTRICAL RATINGS: Rating HP AC Volts Line Min. Input KVA Nominal Max. AC Line Curr. Max. Armature Volts Max. Armature Curr. DC Shunt Motors / Field Volts 1/4 115 .40 3.5 90 3 100 1/3 115 .60 5.2 90 3.7 100 1/2 115 .80 7.0 90 5.2 100 3/4 115 (230) 1.15 10.1 (5.4) 90 (180) 7.8 (3.9) 100 (200) 1 115 (230) 1.61 14.0 (7.0) 90 (180) 10.0 (5.0) 100 (200) 1- 1/2 230 2.40 10.5 180 7.7 200 2 230 3.22 14.0 180 10 200 BICL's SALE TERMS WARRANTY: This unit comes with a 1 yr limited warranty as per the terms and conditions of the Terms of Sale. Contact us for more information. PAYMENT TERMS: We accept payments through PayPal only. SHIPPING:Please Be Aware: Our $16.00 flat fee for shipping (Canada and US) $25.00 for Europe, handling, and insurance is for 2-10 business day air-mail delivery via Canada Post. This flat rate quote applies to buyers located in Canada and Continental USA only. Please contact us for a shipping quote if you are located elsewhere, as we ship WORLDWIDE! For a faster shipping option, such as FedEx, please contact us before paying so that we can quote you on your actual shipping charges. Discounts on shipping/handling/insurance costs are offered to buyers of 5 units or more. RESTRICTIONS: We reserve the right to refuse bids from bidders with NEGATIVE ratings (total rating points is below zero). NOTE: Canadian purchasers must pay all relevant taxes. Add an SMC Reversing Kit Option (RKO) ONLY $40.00 ! Or better yet, let us put the whole unit together for you in an enclosed model (SMC-N412R) DC Motor Controller 1/2 - 1 1/2 HP 115/230VAC (Power On/Off, Toggle, Speed Pot., Special Reversing Toggle, Dynamic Brake, Enclosed Model) ONLY $375.00!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	SMC-00
Brand	BICL
Country/Region of Manufacture	Canada
