DC Motor Reverse Polarity Switch DPDT Relay Module DC 5-13V 2A Time Adjustable, US $3600 – Picture 0
DC Motor Reverse Polarity Switch DPDT Relay Module DC 5-13V 2A Time Adjustable, US $3600 – Picture 0

Dc Motor Reverse Polarity Switch Dpdt Relay Module Dc 5-13v 2a Time Adjustable

US $3600

  • Shenzhen , China
  • Nov 5th
Open on mobile:
QR code
Product Introduction: 1.Operating Voltage:DC 5-13V 2.Operating Current:forward rotate 4mA;backward rotate 36mA (5V)                     forward rotate 6mA;backward rotate 44mA (12V) 3.Load Voltage:DC 1-48V;AC 85-265V 4.Load Current2A (max) 5.Forward Rotating Maximum Time:5000s (through short circuit bonding pad can reach 40000s),step 0.1s 6.Backward Rorating Maximum Time:5000s (through short circuit bonding pad can reach 40000s),step 0.1s 7.Size:54mm*22mm*15mm Connection Introduction: 1.VIN:connect with operating power positive  2.GND:connect with operating power negative  3.P+:connect with motor power positive  4.P-:connect with motor power negative  5.M+:connect with motor input port 1 (motor regardless of positive or negative) 6.M-:connect with motor input port 2 After power on,D1 flash for three times and then off,D2 off,M+ output positive,M- output negative,motor foreward rotating;after delay for T1,D2 on,M+ output negative,M- output positive,motor backward rotating;after delay for T2,D2 off,M+ output positive,M- output negative,motor foreward rotating and so on  T1:represent foreward rotate delay time,default 0.1-5000s adjustable (step 0.1s);by bonding pad can set 1-8 times delay (the longest 40000s) T2:represent backward rotate delay time,default 0.1-5000s adjustable (step 0.1s);by bonding pad can set 1-8 times delay (the longest 40000s) Product Picture: Wiring Diagram: Operating Principle: After power on,D1 flash for three times and then off,D2 off,M+ output positive,M- output negative,motor foreward rotating;after delay for T1,D2 on,M+ output negative,M- output positive,motor backward rotating;after delay for T2,D2 off,M+ output positive,M- output negative,motor foreward rotating and so on T1:represent foreward rotate delay time,default 0.1-5000s adjustable (step 0.1s);by bonding pad can set 1-8 times delay (the longest 40000s) T2:represent backward rotate delay time,default 0.1-5000s adjustable (step 0.1s);by bonding pad can set 1-8 times delay (the longest 40000s) inkfrog terapeak inkFrog Analytics
