Dc To Dc Power Converter Boost Buck Power Supply Volt Regulator 5-32v To1.25-20v

US $17.80

Guangzhou ,Guangdong, China
Feb 26th

Open on mobile:
QR code

DC to DC converter 5-32V to 1.25-20V Automatic Boost and buck power supply Voltage Regulator Solar Wind Energy Adjustable Regul Description DC to DC converter 5-32V to 1.25-20V Automatic Boost and buck power supply Voltage Regulator Solar Wind EnergyAdjustable Regulated power supply #1300203 60W buck and boost module automatically DC5-32V wide input voltage DC1.2-20V adjustable output voltage Wide Maximum output current 5A Module parameters: Module name: 5A automatic step-up/step-down module Module Properties: non-isolated synchronous rectifier step-up/step-down module automatically Input voltage : DC5-32V Input Current: 8A (MAX) ,work long hours <= 6A. Quiescent Current: 3mA (Operating Voltage Different,There will be errors) Output voltage: DC1.25-20V continuously adjustable Output Current: 5A (MAX) (it can be long time susing when natural cooling out put current <=3A) For higher output current, two modules can be used in parallel, such as the output to 6A, you can use two modules in parallel, the current of each module can be transferred to 3.5A. Operating temperature: -40 to +85℃ Operating Frequency: 150KHz Conversion efficiency: Up to 96% (efficiency and input and output voltage, current, voltage dropout related) Current protection: yes Short circuit protection: (enter the 10A fuse) double circuit protection, use more secure. Over-temperature protection: Yes (over-temperature automatically reduces the output voltage) Input Reverse Polarity Protection: None, (if required in the input string into diode) Installation: four 3mm screws Connection: welding output, (V-IN as an input, V-OUT is the output) Module dimensions: length 60mm* width 40mm* height 30mm Applications: This module can be applied to relatively large fluctuations in the input voltage, the output requirements are relatively stable area. Such as: 1, the 12V battery float voltage 10-14V 12V output stable. 2, for your electronic systems over a wide input voltage range to provide a stable operating voltage. 3, the output of solar panels float voltage regulated output to charge the battery to prevent battery overcharge. 4, DIY a power supply, input 12V , can be 12-20V adjustable output packing including: 1x Automatic Boost and buck power supply Payment We only accept payments via paypal. All payments must be prepaid, no Cash and COD payment. We will ship the item to the address on your paypal payment notice, Please confirm your shipping address in the PayPal Account. If you have any problem about payment , please contact us. Delivery details Item will be shipped within 3 working days after full payment is received. We ship worldwide with flat rate shipping by post Air mail, the shipment usually takes 15-45 business days . We can also provide express post by EMS(5-8 days) or UPS(4-5 days). The cost is higher than standard postage, extra shipping fees is needed. if you need express post please contact us ! About us We will leave positive feedback to buyer as soon as buyer pays for the item .Your satisfaction is our first priority. Please leave us positive feedback upon satisfaction of the item. Please email us before leaving negative and neutral feedback. We will try our best to solve the issue. We will leave positive feedback to buyer as soon as buyer pays for the item . Contact us we do try respond as quickly as possible. Due to time zone difference, please allow 12~24 hours to get your mail replied. If you have any questions, Please contact with us via ebay message or our customer service e-mail .thanks for your buying ,wishes you have a happy shopping from our shop ! Engineered for professional eBay sellers!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	module name	DC to DC converter Automatic Boost buck
Quiescent Current	3mA
product name	power supply Voltage Regulator
Output voltage	DC 1.25-20V continuously adjustable
put voltage	DC 5-32V
Output Current	5A (MAX) long using <=3A
Input Current	8A (MAX) ,work long hours <= 6A.
