Dds Function Signal Arbitrary Waveform Generator 10mhz Usb 3.5" Tft Lcd Sdg810

US $265.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Note: we'll ship this item via express mail service to USA, Canada, Australia, New Zealand, Ireland, Austria, Belgium, Denmark, Germany, France, Finland, Luxemburg, Malta, Norway, Sweden, Swiss, Spain, Italy, UK, Japan, Korea,Thailand, Malaysia, Indonesia, Philippine, Singapore. Clients from other countries pls contact with us in advance to confirm the different shipping charges before you bid. SDG810 Overview: SDG800 Series Function/Arbitrary Waveform Generator is equipped with maximum output frequency of 5 MHZ, 10 MHZ, 30 MHZ, and 125 MSa/s sampling rate. With the new innovated EasyPulse technology, SDG800 can generate pulse of low jitter, quick rising/falling edge regardless of frequency effect, while the duty cycle, edge and pulse width could be widely and accurately adjusted. SDG800 is much superior in performance to similar DDS signal generator. Main Features: ? Advanced DDS technology,125MSa/s sampling rate, 14bit vertical resolution ? Single channel output, 5 kinds of standard waveforms, built-in 46 kinds of arbitrary waveforms (including DC) ? Complete modulation functions: AM, DSB-AM,FM, PM, FSK, ASK, PWM, linear/logarithmic sweep and burst ? Innovative EasyPulse technology, can output pulse of low jitter, quick rising/falling edge ? Standard interfaces: USB Device, USB Host, support U-Disk storage and software update ? Provide 10 nonvolatile storage spaces for user’s arbitrary waveforms ? Be capable of seamlessly connected to SIGLENT Digital Storage Oscilloscope ? Configurable with powerful arbitrary waveform editing software EasyWave Model SDG805 SDG810 SDG830 Maximum output frequency 5MHz 10MHz 30MHz Output channels 1 Sampling rate 125 MSa/s Wave length 16 kpts Frequency resolution 1 ?Hz Vertical resolution 14 bits Waveform Sine?Square?Ramp?Pulse?Gaussian white noise?Arbitrary waveform,46 types of built-in arbitrary waveforms Sine wave 1?Hz ~ 5MHz 1?Hz ~ 10MHz 1?Hz ~30MHz Square wave 1?Hz ~ 5MHz 1?Hz ~ 10MHz 1?Hz ~10MHz Pulse 500?Hz ~ 5MHz 500?Hz ~ 5MHz 500?Hz ~5MHz Ramp/Triangular 1?Hz ~ 300KHz 1?Hz ~ 300KHz 1?Hz ~ 300KHz Gaussian white noise >5MHz bandwidth(-3dB) >10MHz bandwidth(-3dB) >30MHz bandwidth(-3dB) Arbitrary waveform 1?Hz ~ 5MHz 1?Hz ~ 5MHz 1?Hz ~ 5MHz Modulation function AM?FM?PM?DSB-AM?FSK?ASK?PWM?Sweep?Burst Standard configuration USB Host & USB Device Amplitude (High resistence) 4mVpp~20Vpp(HighZ), 2mVpp~10Vpp(50ohm) Frequency Specification Model SDG805 SDG810 SDG830 Waveform Sine, Square, Ramp, Pulse, Noise, Arbitrary Sine 1?Hz ~ 5MHz 1?Hz ~ 10MHz 1?Hz ~ 30MHz Square 1?Hz ~ 5MHz 1?Hz ~ 10MHz 1?Hz ~ 10MHz Pulse 500?Hz ~ 5MHz Ramp/Triangular 1?Hz ~ 300kHz Gaussian white noise >5MHz (-3dB) >10MHz (-3dB) >30MHz (-3dB) Arbitrary 1?Hz ~ 5MHz Resolution 1?Hz Accuracy Within 90days ±50ppm within 1 year ±100ppm Temperature coefficient <5ppm/°C Sine Wave DC~1MHz <-60dBc 1MHz~10MHz <-55dBc Harmonic Distortion 10MHz~30MHz <-50dBc Total harmonic waveform distortion DC~20kHz,1Vpp<0.2% Spurious signal(non-harmonic) DC~1MHz<-70dBc 1MHz~10MHz<-60dBc 10MHz~30MHz<-55dBc Phase noise 10kHz Offset,–108dBc/Hz(typical value) Square Wave Rise/fall time <24ns(10% ~ 90%) Overshoot <5%(typical,1kHz,1Vpp) Duty Cycle 20%~80% Asymmetric(50% Duty Cycle) 1% of period+20ns(typical,1kHz,1Vpp) Jitter 500ps + 0.001% of period Ramp/Triangle Wave Linearity <0.1% of Vpp(typical,1kHz,1Vpp,100% symmetric) Symmetry 0%~100% Pulse Wave Pulse width 16ns, Min. 1ns resolution Rise/Fall time (10% ~ 90%,typical) 20ns~1.6ks Duty Cycle 0.1%Resolution Overshoot <5% Jitter(pk-pk) 500ps + 0.001% of period Arbitrary Wave Waveform length 16k points Vertical resolution 14bits Sample rate 125MSa/s Min. Rise/Fall time 8ns(typical) Jitter(pk-pk) 8ns(typical) Storage in non-volatile RAM memory (10 in total) 10 waveforms Output Specification Amplitude 2mVpp~10Vpp(50?,

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	SDG810
Country/Region of Manufacture	China
MPN	SDG810
