fslr Photo 1.RAMPS 1.4 It is a Mega Pololu Shield, or RAMPS for short,designed to fit the entire electronics needed for a RepRap in one small package for low cost. RAMPS interfaces an Arduino Mega with the powerful Arduino MEGA platform and has plenty room for expansion. The modular design includes plug in stepper drivers and extruder control electronics on an Arduino MEGA shield for easy service, part replacement, upgrade-ability and expansion. Additionally, a number of Arduino expansion boards can be added to the system as long as the main RAMPS board is kept to the top of the stack. This board is mostly based on Adrian's Pololu_Electronics and work by Tonok. Copper etch resists methods suggested by Vik. Also inspired by Vik's work with EasyDrivers. circuit design based mostly on Adrian's Pololu_Electronics Joaz at RepRapSource.com supplied initial pin definitions and many design improvements. Much inspiration, suggestions, and ideas from Prusajr, Kliment, Maxbots, Rick, and many others in the RepRap community. 2.Mega 2560 Arduino Mega is an ATmega2560 as core microcontroller development board itself has 54 groups digital I / O input / output terminal (14 groups do PWM outputs), 16 sets of simulation than the input side, group 4 UARTs (hardware serial ports), using the 16 MHz crystal oscillator. With the bootloader, download the program directly via USB without having to go through other external writer. Supply part of the optional USB power, or as an external power using the AC-to-DC adapter and battery. Arduino development IDE interface is based on open-source principles, allows you to free download for use in project work, school teaching, motor control, interactive works. 3.DRV8825 driver The DRV8825 stepper motor driver carrier is a breakout board for TI’s DRV8825 microstepping bipolar stepper motor driver. The module has a pinout and interface that are nearly identical to those of our A4988 stepper motor driver board, so it can be used as a higher-performance drop-in replacement for those boards in many applications. The DRV8825 features adjustable current limiting, overcurrent and overtemperature protection, and six microstep resolutions (down to 1/32-step). It operates from 8.2 – 45 V and can deliver up to approximately 1.5 A per phase without a heat sink or forced air flow (rated for up to 2.2 A per coil with sufficient additional cooling). 4. Reprap smart RAMPS1.4 LCD2004 display controller The Smart Controller gives your 3D printer the possibility to print "stand alone", without any PC! 5.Mechanical Endstop Mechanical Endstop perfect for any 3D printer (Including Prusa Mendel i2, Prusa i3, MendelMax, Rostock etc...) also for use on CNC machines and other electronic applications. 6.SD Ramps Breakout board for the microSD socket that is not much bigger than your fingernail. Compatible with the SPI interface found on any SD card, this tiny form factor was created for cell phone storage and is perfect for your next 3D printer project! Board comes fully assembled and tested.The bare socket is available. 7.310mm delta rostock heated bed 3d hot bed description:? 310mm overall diameter? 280mm hot zone? designed for 12V operation, can be used with 24v pwm signal to limit etc ...? 3 mm diameter holes spaced 12 mounting a pattern diameter 300mm? 1 x soldered and assembled RAMPS 1.4 shield 1 x Aduino Mega 2560 1 x USB cable 5 x soldered DRV8825 stepper driver 1 x Soldered and assembled panel with 4 rows LCD,SD card connector,a rotary encoder 1 x Samrt Controller 4x Mechanical Endstops V1.2 1 x cooler fan 1 x 310mm delta rostock heated bed Payment We accept paypal only. Shipping ? Generally, delivery time is 7-14 business days to USA, United Kingdom, Australia and 7-25 days to most other countries. ? We will make shipment within 48 hours once the payment is clear (Saturday and Sunday are not included) All items will be dispatched from our warehouse and shipped via HongKong Post Air-mail. ? We will make shipment according to the address you put on eBay, if you want us to ship items to a different address please contact us before making the payment. ? If you can’t receive the package for more the 4 weeks, please contact us, thanks! ? Items can be combined into one invoice but the total shipping fee will be the sum of each item's shipping & handling charge. Return Policy Wealways take customer service seriously and want you to be 100% happy with your shopping experience here. If you have any queries please contact our team by email first before leaving any negative feedbacks we will email back to you within 24 hours!! · If you are unsatisfied with our item or service, then please follow the good eBay practice to contact us before leaving any feedback and return it within 7 days for a replacement or money back. · Please contact me before you return it. · Buyer is responsible for the shipping cost of return postage. · Shipping and insurance costs will not be refunded. · Weare committed to resolve all issues in a friendly and satisfactory manner.
