Deview-wide Dynamic Color Camera - Model: Cfh22wd - New In Box

US $35.00

San Marcos, California, United States
Jan 30th

Open on mobile:
QR code

Day/Night high resolution box type camera for tracking applications. new in box 1/3" format CCD Day/Night and wide dynamic 480 TV Lines in normal mode 500 TV Lines in color killer mode Operates on 12VDC or 24VAC Automatic lens detection CS and C mount lens support SIMILAR TO & REPLACED BY MODEL: CQ3TN5622 COLOR, WIDE DYNAMIC, HIGH-RESOLUTION CAMERA WITH DAY/NIGHT MODE AND 12VDC/24VAC OPTION KEY FEATURES 1/3" format CCD Day/Night and wide dynamic 480 TV Lines in normal mode 500 TV Lines in color killer mode Operates on 12VDC or 24VAC Automatic lens detection CS and C mount lens support The ultimate in versatility. Day or night. Color or black and white. Your choice of 12VDC or 24VAC power. For uncompromising round-the-clock surveillance, monitoring and security, this is the camera you need. GENERAL SPECIFICATIONS Image Size 1/3" format SONY wide dynamic CCD sensor Pixel Element 768 (H) x 494 (V) approx. 380K pixels Scanning Frequency NTSC 2 : 1 Interlace / H : 15750Hz , V : 59.94Hz Operation Temperature -10 degrees C ~ 50 degrees C Storage Temperature -20 degrees C ~ 60 degrees C Output Terminal BNC 75Ohm unbalance Input Terminal 2pin screw type terminal block Power Operation Range 10.6DCV ~ 30VDC / 12VAC ~ 28VAC 60Hz Power Consumption 4.5W max. Power Indicator Green LED on rear panel IRIS Connector Video drive: 3pin push lock terminal block on rear, DC drive: 4pin connector on side Lens Mount CS ~ C mount adjustable Back Focus Adjust CS aount 11mm ~ C aount 18mm Mounting Hole 1/4" top and bottom External Dimension 58mmW x 66mmH x 131mmL CERTIFICATES STANDARD FCC Certificate FCC part 15, subpart B, Class B, ANSI C63.4-1992 FUNCTIONAL SPECIFICATIONS Exposure Control Auto electronics shutter / video auto IRIS / DC auto IRIS AES Auto luminance control 1/60 ~ 1/100000 sec max. Auto IRIS Control Video drive / DC drive separate output Video IRIS Output 1.0Vpp ( 100IRE video output ) DC IRIS Output 650mV at 85Ohm impendent Wide Dynamic Range 52dB BLC Center srea for suto IRIS and AES White Balance Auto white balance Auto White Balance Range 2500K ~ 9500K Day and Night Color killer auto detect by luminance (Fuzzy 30IRE ~ 80IRE) AGC Boost Enhance AGC gain to max. 36dB Color Killer Fuzzy ON / OFF SYNC System INT / line lock Line Lock Phase adjust Range:0 degrees ~ 270 degrees , Frequency Range: 60Hz /- 1Hz VIDEO SPECIFICATIONS Resolution Normal mode: 480 TV Lines, CK mode: 500 TV Lines Minimum Illumination 0.6Lux @ F=1.2 ( 50IRE video output ) Video Output 1.0Vpp 75Ohm BNC unbalance S/N Ratio 50dB AGC Preset Gain 30dB H Aperture 10 IRE ( r 0.45 100IRE Video Output ) V Aperture 10 IRE ( r 0.45 100IRE Video Output ) Gamma Compensation 0.45 FUNCTION CONTROL OR ADJUSTMENT SPECIFICATIONS Exposure Control Auto electronics shutter / auto IRIS select by DIP switch. Manual Exposure Control AES / video drive / DC drive Color Killer Fuzzy ON / OFF BLC ON / OFF switchable Wide Dynamic ON / OFF selectable SYNC System INT / LL switchable on rear panel V-Phase Via resistor on rear panel

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	CFH22WD
Brand	DEVIEW
Model	CFH22WD
Color Mode	Color
Camera Type	Box/Body
Type	Cameras
