Dew Point Monitor/carbon Monoxide Combination Unit

US $2,700.00

Pembroke, Massachusetts, United States
Jan 30th

Open on mobile:
QR code

CALL WITH QUESTIONS - 508-230-7118 The model DCM 28 is a Dew Point and CO Monitor Measuring Dew Point and CO in Medical air applications and in compliant with NFPA99 Dew Point and CO Analyzer This medical gas analyzer was design for fast, accurate and economic measurement of CO and Dew Point in medical air applications. A simple menu-driven software and LED- display allows easy and fast start-up of the instrument. Ranges The CO can be measured in the range of 0 – 50 ppm and the dew point in the range of -40°C up to 60°C. Alarms 2 programmable alarm contacts, 1form B 3A at 250Vac" This unit includes an alarm out via contact and an audio alarm (95 db). Relay Set points for Dew Point and CO. Sensor operating life The CO sensor is an electrochemical sensor. It gives you a sensor life of 2 years with a drift Rate of < 5%/yr. The drift can be corrected via calibration using a calibration gas if necessary. The RH capacitance sensor is durable and can be either recalibrated or replaced in the field very quickly by exchanging sensor tips while maintaining the sensor accuracy The Model DCM 28 is a standalone unit, complete with a small sampling system with all the needed accessories. Benefits Compact economic instrument with sensors remotely separated from the electronics Sensors with long operating life. No range switching required Features 2 line LCD display (displaying the CO and the dew point) audible and visual alarm Dew point in C or F (selectable) Includes sample system for both sensors, all in one enclosure Easy installation Hinged door NFPA 99 compliant Specification of Dew point sensor Measuring range : -40 to 60C Specification of CO sensor Measuring Range : 0 – 50 ppm CO Calibration : with calibration gas Accuracy : +/- 2% of measuring Resolution : 0,1 ppm Response time : 90 % of FSD at 25°C < 45 s Operating Temperature : 0 - 50°C Sample pressure : 0,1 - 1 barg Output signal : 4 -20 mA/DC isolated Alarm : 1 form B relay 3A 250V Voltage : 24 VDC Sensor : electrochemical sensor Sensor warranty : 1 year from dispatch Expected sensor life : minimum 2 years Calibration: field replaceable sensor (no cal needed) available Accuracy : typical +/-1C Resolution : 0,1 ppm Response time : 66% change in <10sec Operating Temperature : 0 - 50°C Sample pressure : 0-200psi (dew point reading at pressure) Output signal : 4 -20 mA/DC Isolated Alarm : 1 form B relay 3A 250V Voltage : 24 VDC Sensor : capacitive sensor Sensor warranty : 1 year from dispatch Expected sensor life : 2 years

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Compressor World
Model	DCM 28
