Digilent Nexys2 Xilinx Spartan-3e 500k Fpga Board

US $137.50

  • Denver, Colorado, United States
  • Jun 9th
Open on mobile:
QR code
Used Digilent Nexys™2 Spartan-3E FPGA Board.  Powers up on USB and passes diagnostic test - see photo. Includes the FPGA board and USB cable only. The software for configuring the FPGA and flash devices is at www<dot>digilentinc<dot>com (Digilent Adept).  Digilent sells this board for $270/($189 Academic price). Free shipping to USA only.  Please request a shipping quote for locations outside USA. The FPGA development software is a free download (WebPACK) and is at www<dot>xilinx<dot>com.  I am an engineer who uses Xilinx WebPACK software.  And I have developed FPGAs with this Nexys2 (using another Nexys2 system of my own) and I have found the Digilent boards to be high quality and work great.  This is a very large FPGA (500K) - so it can accommodate large design projects (including MicroBlaze embedded processor).  Please note that some Digilent Nexys2 boards have smaller Xilinx FPGAs (e.g. 200K). (From the Digilent website) The Nexys 2 is a powerful digital system design platform built around a Xilinx Spartan 3E FPGA. With 16Mbytes of fast SDRAM and 16Mbytes of Flash ROM, the Nexys 2 is ideally suited to embedded processors like Xilinx's 32-bit RISC Microblaze™. The on-board high-speed USB2 port, together with a collection of I/O devices, data ports, and expansion connectors, allow a wide range of designs to be completed without the need for any additional components. Xilinx Spartan-3E FPGA 500K gate USB2 port providing board power, device configuration, and high-speed data transfers Works with ISE/Webpack and EDK 16MB fast Micron PSDRAM 16MB Intel StrataFlash Flash R Xilinx Platform Flash ROM High-efficiency switching power supplies (good for battery-powered applications 50MHz oscillator, plus a socket for a second oscillator 75 FPGA I/O’s routed to expansion connectors (one high-speed Hirose FX2 connector with 43 signals and four 2x6 Pmod connectors) All I/O signals are ESD and short-circuit protected, ensuring a long operating life in any environment. On-board I/O includes eight LEDs, VGA, UART (RS232), PS2, four-digit seven-segment display, four pushbuttons, eight slide switches Ships in a DVD case with a high-speed USB2 cable
