Digital Transistor Tester,m328 Capacitance Resistance Meter Resistance Tester~

US $28.47

suzhou, China
May 13th

Open on mobile:
QR code

Product Description Digital Transistor Tester,M328 Capacitance Resistance Meter Resistance Tester~ Features: 100% brand new and high quality Made of high-quality materials, durable One-button measurement operation, automatic power off after delay. The shutdown current is only 20nA, which supports battery operation. Automatic detection of PNP and NPN bipolar transistors, N-channel and P-channel MOSFETs, JFET field effect transistors, diodes, double diodes, SCR, resistance, capacitance, inductance. Automatically detect pin definitions. Measure the current amplification factor (B) of the bipolar transistor and the conduction voltage (Uf) of the emitter junction. Darlington transistors can be identified by high threshold voltage and high current amplification factor. It can detect the protection diodes inside bipolar transistors and MOSFETs and display them on the screen. Measure the threshold voltage and gate capacitance of the MOSFET. It supports the measurement of two resistances and can also measure potentiometers. If the potentiometer is adjusted to one end, the tester cannot distinguish between the middle pin and the end pin. The resolution of resistance measurement is 0.1 ohm, and the highest measurement value is 50M ohm. The capacitance measurement range is 25pf to 100mF (100,000UF). The resolution is up to 1 pF, and the inductance measurement range is 0.01 MH-20H. Otherwise, it will show as resistance. If the DC resistance of the inductor is higher than 2100 ohms, it will also show up as a resistor. In the capacitance test, the VLoss displayed on the screen means loss and attenuation. The larger the value, the closer the capacitor will be scrapped! ESR is impedance. The smaller the value, the better the performance of the capacitor! It can detect the equivalent series resistance (ESR) of capacitors above 2UF with a resolution of 0.01 ohm. This function is very important for detecting capacitance performance. Two diodes with correct direction symbols can be displayed, and the forward voltage drop can be displayed. The LED is detected as a diode, and the forward voltage drop is higher than normal. The dual LED is detected as a dual diode. During the test, the LED will flash. The time for each test is about 2 seconds. Only large capacitance and inductance measurements take a long time. Product parameters: Color: black + gray Material: PCB + plastic Display: 1.8-inch TFT color display Shutdown current: 20nA Power supply: DC9V 6F22 battery (not included) Size: 135X70X24mm /5.31"X2.76"X0.94" (approximately) Automatic identification: transistor, diode, double diode, MOS, SCR, resistor, inductor, capacitor, capacitor ESR Transistor range: less than 2 (including 2) transistors, composed of PN junctions. No other resistance components inside Resistance test range: 0.5-50M Inductance test range: 0.01mH-20H Capacitance test range: 25pf-100000uF Simple instructions: 1, 2, and 3 pins are not connected, automatically identify the type, automatically detect the needle sequence, display graphics, and automatically measure parameters. (For example, if you pick up the transistor, you don't have to consider the order of the 1, 2 and 3 pins of the BCE, just insert it. Then press the test button. It will automatically recognize whether it is a triode, FET, thyristor or resistor. After it is recognized as a triode, test whether it is NPN or PNP, then determine the BCE order, display it in a graph, and then tell you the magnification, turn-on voltage, etc. You just need to plug in the power supply and press the button, and the rest will tell you what it is. ) Package list: 1 *Transistor tester (excluding battery) Note: 1.The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2.Please allow slight manual measurement deviation for the data. Payment We accept payment via Paypal only. Payment must be completed within 5 days. If you have any problems about payment, please contact us via ebay message. Delivery details We only ship to confirmed Paypal addresses. Please comfirm that your paypal address is in line with your shipping address. Please kindly note that the combined shipping is not provided because the shipping fee is calculated by weight. Also, the each additional item means exactly the the same color and size. It takes about 7-15 working days to US; about 10-30 working days to other countries. Transit time may be a little delayed because of the bad weather and customs inspection. If you do not receive your item within 30 working days since payment finished, please contact us immediately for further assistance. Contact us We strive for 100% customer satisfaction! Positive Feedback is very important to us. If you have any questions, please feel free to contact us via "Ask seller a question" . We will reply your email within 24 working hours.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
Display	1.8-inch TFT color display
MPN	Does Not Apply
Shutdown current	20nA
Product	Transistor tester (excluding battery)
Power supply	DC9V 6F22 battery (not included)
Package Contents	1 *Transistor tester (excluding battery)
Size	135X70X24mm /5.31
Color	black + gray
Capacitance test range	25pf-100000uF
Material	PCB + plastic
UPC	Does not apply
