Ditek Dtk-pvpip Ip/poe Camera Surge Protector

US $4600

  • Champlin, Minnesota, United States
  • Jun 1st
Ditek DTK-PVPIP IP/PoE Camera Surge Protector The Ditek PVPIP protects IP/PoE Video cameras and systems from surges on the network cabling and power supply lines. Low-impedance video/data protection allows full Gigabit Ethernet transmission speed; the 12V or 24V power protection is rated for 5 Amps per pair to power camera plus heaters, blowers, defrosters, or PTZ motors. The PVPIP provides optimum protection of power, data and video connections in a single product. Features: Can be used at Camera or individual NVR/Power supply feed RJ45 connection protects all four video/data pairs Two pairs of power protection External grounding screw Conforms to EIA/TIA standards for data transmission Complies with IEEE Std. 802.3af and 802.3at for PoE PoE Plus ready for high-wattage applications Automatically resets to protect against multiple surges Technical Specifications: Data Rate: Gigabit Ethernet using all four pairs Connection: Video/Data: RJ45 In/Out, 8 pins; Power: #22-#14AWG screw terminals Max Continuous Current: 1.5A Video/Data, 5A Power Protection Modes: Line-Ground (All) Dimensions: 4.2" x 3.25" x 1.75" (107 x 83 x 44mm) Weight: 5oz (141g) Housing: ABS
