Diy Kits Capacitance Esr Inductance Resistor Meter Tester Npn Pnp Mosfet M168

US $17.39

United States
Jan 29th

Open on mobile:
QR code

Features: 1 : a key measurement operation , auto power off delay . Shutdown current is only 20nA, support battery operation. 2 : Automatic detection PNP and NPN type bipolar transistors , N, P -channel MOSFET, JFET FET , diodes , two diodes, thyristors , resistors , capacitors , inductors . Automatic detection pin definitions. 3 : Measurement of the bipolar transistor current amplification factor (B) and conduction voltage emitter junction (Uf). Darlington transistor may be identified by the amplification factor of the high threshold voltage and high current . 4 : can be detected inside the bipolar transistor and MOSFET protection diodes and displayed on the screen. 5 : the threshold voltage and the MOSFET gate capacitance measurement . 6: Support two measuring resistors , the potential can also be measured . If the potentiometer is adjusted to its end , the tester can not distinguish the two ends of the pin and the middle . 7 : Resistance measurement resolution is 0.1 ohm , the highest measurement value of 50M ohms. 8: capacitance measurement range from 25pf to 100mF (10UF). Resolution up to 1 PF. 9: can detect more than 2UF capacitor equivalent series resistance (ESR), with a resolution of 0.01 ohms. This feature is very important for the detection capacitor performance. 10 : You can display symbols of the two diodes in the right direction , also shows the forward voltage drop . 11: LED detection of diode forward voltage drop higher than normal . Dual LED detected as double diodes. Simultaneous detection of light-emitting diodes will flash . 12: each test time is about two seconds , only large capacitance and inductance measurements will take a long time . Specifications: Measurement Range: Resistor:0.5 ?-50M? Capacitor:30pF-100mF Inductance:0.01MH-10H Working voltage: can use 6FF22 9V Battery, or DC 5.5-12V via DC socket. Controller :ATmega168 Standby current: 0.02uA Operating current: 25mA Package Contents: 1 Meter(without the battery), DIY Kits, not soldered, Atmega168 has been programmed. Important Notes: 1. This seller uses an automated feedback system. A positive feedback will be posted for the buyer at the time the seller receives a feedback from the buyer. If you do not receive feedback after leaving feedback, please contact the seller. 2. This seller strives to process and ship items within 24-48 hours after payment. Some unforeseen circumstances may arise where this is not possible. If tracking information has not been upload to the transaction after 48 hours please contact the seller as this may have simply been an over sight. 3. Pictures are for reference only. Due to computer monitor difference, actual products receive may vary. 4. International orders may be shipped from overseas warehouses for faster delivery or what ever may be the most economical for the seller. Overseas warehouses includes; Brazil, United Kingdom and China. Returns: If there is a problem, please work together with this seller to resolve the problem. Negative feedback doesn't go away and should only be left as a last resort! This seller strives for positive feedback, harmonious customer relations. 1. Item must be returned to the seller within 14 days of delivery. 2. Buyer is responsible for return shipping. 3. If the item is Dead on Arrival (DOA) The seller will pay the shipping charge for sending the buyer the replacement item. 4. This seller must first receive the item to verify returns claims before a refund or exchange will be completed. 5. Items returned for non-seller mistake reasons, ie; buyer changes mind of purchase, purchased wrong color, etc..., may be subject to restock fee. (Restocking fee includes all fees that the seller incurred to send buyer the product purchased including: original shipping fees, eBay fees and PayPal fees.) inkfrog terapeak i000000
