Diydrones Arduimu+ V3

US $7200

Melbourne, Florida, United States
Jun 9th

Open on mobile:
QR code

DIYDrones ArduIMU+ V3 Description: The ArduIMU+ V3 is the latest and greatest version of DIYDrones' smart IMU. This time they've made it smaller and faster by incorporating the new Invensense MPU-6000 3-axis gyro and accelerometer as well the 3-axis I2C magnetometer HMC-5883L. With the GPS port and on-board Atmega328 microprocessor, the ArduIMU+ V3 is a tiny but powerful orientationsolution. This version of the board is pin compatible with V2, but unlike V2 it's also breadboard friendly! This device is suitable for any application from rockets to simple movement detection. Note: The board comes with a row of right-angle headers, as shown in the pictures. They come unsoldered. Dimensions: 1.5" x 1.0" Features: 3-Axis gyro with sensitivity up to 131 LSBs/dps and a full-scale range of 250, 500, 1000, and 2000dps 3-Axis accelerometer with a programmable full scale range of 2g, 4g, 8g and 16g Reduced settling effects and sensor drift by elimination of board-level cross-axis alignment errors between accelerometers and gyroscopes Full Chip Idle Mode Supply Current: 5A On-chip timing generator with 1% frequency variation over full temperature range User self test 10,000g shock tolerant Pin compatible with ArduIMU V2 The 6 analog pins are nowavailable! Arduino compatible and open source. 3 status LED's (RGB). I2C port with 3.3Vtranslation. GPS port with FTDI autoswitch. Documents: Schematic Eagle Files Google Code Page Datasheet (MPU-6000) Datasheet (HMC5883L) Datasheet (Atmega328) Working on a project? Call us about bulk orders! 1-888-226-4711 We ship from the United States! Click on the image below to get zoomed view of the item Payment Policy PayPal is the only method of payment. PAYMENT MUST BE MADE WITHIN 24 HRS OF PURCHASING Items ship within 72 hours upon receipt Shipping & Return Policy We appreciate your business and look forward to working with you on your projects. We'd like you to know that each order that we receive is treated like the only order we receive. We will do our best to respond to your inquiry immediately. Lead time: For orders before 2 PM we strive to ship packages same day. Customers can expect their orders to be shipped within one business day. Return Policy: We will accept returns within 14 days of receiving your package. The product or products you return must be new in the unopened package, without damage, without solder paste, in working condition. Faulty, damaged, or broken product: You will be required to document, take a picture and contact us immediately upon arrival of your item. Upon receiving notification of your damaged item we will generate a return mailing label that will be emailed to you. Go ahead and put that label on the same box or envelope you received, apply tape where necessary and send back to us. We will repair or replace the item. This does not apply to damage caused by delivery company. Damaged package: If a box or envelope appears to be damaged please contact the delivery company (USPS, UPS, FEDEX) and file a claim with them. Terms Of Sales If you have ANY problems please contact us before leaving a negative feedback. Negative feedback will not solve the problem. Please contact us if you have any question or complaint immediately. We love to work with you to solve the problem! Your feedback is important for us to grow our business on ebay. So, please do leave feedback. Contact Us Phone: 1-888-226-4711 Address: Jaycon Systems LLC 801 E. Hibiscus Blvd #2 Melbourne, FL 32901 We appreciate your comments and would love to hear from you!
