Dlg3416 0.270" 4-character 5 X 7 Dot Matrix Alphanumeric Intelligent Display

US $16.34

Stara Zagora, Stara Zagora, Bulgaria
Mar 11th

Open on mobile:
QR code

DLG3416 0.270" 4-Character 5 x 7 Dot Matrix Alphanumeric Intelligent Display® Devices with Memory/Decoder/Driver GREEN Description The DLR/DLO/DLG3416 is a four character 5 x 7 dot matrix display module with a built-in CMOS integrated circuit. The integrated circuit contains memory, ASCII ROM decoder, multiplexing circuitry and drivers. Data entry is asynchronous and can be random. A display system can be built using any number of DLX3416s since each digit can be addressed independently and will continue to display the character last stored until replaced by another. System interconnection is very straightforward. The least significant two address bits (A0, A1) are normally connected to the like-named inputs of all displays in the system. With four chip enables, four displays (16 characters) can easily be interconnected without a decoder. Data lines are connected to all DLX3416s directly and in parallel, as is the write line (WR). The display will then behave as a write-only memory. The cursor function causes all dots of a digit position to illuminate at half brightness. The cursor is not a character, and when removed the previously displayed character will reappear. The DLX3416 has several features superior to competitive devices. True ’’blanking“ allows the designer to dim the display for more flexibility of display presentation. Finally the CLR clear function will clear the cursor RAM and the ASCII character RAM simultaneously. The character set consists of 128 special ASCII characters for English, German, Italian, Swedish, Danish, and Norwegian. All products are subjected to out-going AQL’s of 0.25% for brightness matching, visual alignment and dimensions, 0.065% for electrical and functional. Features • 0.270" High, Dot Matrix Characters • 128 Special ASCII Characters for English, German, Italian, Swedish, Danish, and Norwegian Languages • Wide Viewing Angle: X Axis ±50° Maximum, Y Axis ±75° Maximum • Close Multi-line Spacing, 0.8" Centers • Fast Access Time, 110 ns at 25°C • Full Size Display for Stationary Equipment • Built-in Memory • Built-in Character Generator • Built-in Multiplex and LED Drive Circuitry • Each Character Independently Accessed • TTL Compatible, 5.0 V Power, VIH=2.0 V, VIL=0.8 V • Independent Cursor Function • Memory Clear Function • Display Blank Function for Blinking and Dimming • End Stackable, 4-Character Package • Intensity Coded for Display Uniformity • Extended Operating Temperature Range: –40°C to +85°C • Wave Solderable SHIPMENT Handling time: 2 business days Shipping details: All packages are shipped by priority airmail with provided tracking information (Track. №) Shipping time: EUROPE (All countries): 7 - 14 days ALL OTHER destinations (North America, South America, Asia, Africa, Australia): 10 - 20 days PAYMENT We accept PAYPAL only

““pulled from working device! NOT Tested. 99.9% possibility to work!””

Brand	OSRAM
Country/Region of Manufacture	Germany
Model	DLG3416
