Dow-gage Inspection Bench Machinist Tool Inspection

US $35.99

Arlington, Texas, United States
Mar 1st

Open on mobile:
QR code

Specifications: Model 10 Dow-Gage Die cast aluminum base supports an adjustable indicator mounting post. Internal components consist of a hardened and ground indicator actuator pin, an adjustable over travel stop assembly and a one to one lever assembly for precise linkage from the gage pin in the staging fixture to the dial indicator fastened to the mounting post. Will accept ANSI/AGD Group 2 mechanical and digital electronic indicators as well as Mahr Federal Maxum® electronic indicators with integral AGD backs. The Dow-Gage has a precision central pin that when pressed in the vertical axis, it moves down, as much as you pressed down. This characteristic makes this device to be reliable, consistent and flexible. It’s very comfortable to measure 100% production of a particular feature. Also, the Dow-Gage can be customized to suit your gaging requirements: 1. Changing the central pin to whatever suits your particular inspection will set a gaging for inside step, a piece of cake; 2. Adapting a contact point with an “L” at its end, will allow you to check steps or grooves heights with only one movement from your hand; The Dow-Gage will follow you to whatever imagination it happens you come up with at any particular moment. Besides, since the Dow-Gage’s body is so robust, your setup will be consistent and reliable every time, all the time. Specifications: Standard LS-Platen Body is C1117 steel, lapped and black oxide finished. Round surface is 3"diameter, 4". Pin is 3.500” long by 0.2500” diameter with a ground spherical radius on one end. RC60-63, ground and lapped slide fit in body. As we have mentioned, you could customize the center pin according to your needs. Tin box included. Specifications: MAHR-FEDERAL Indicator; Range: 0 – 0.150”; Accuracy: 0.0005” Suited for both, digital and analog readout with digital output. Model works in inch and metric system (depending on what drop indicator it happens you have installed), furnished with integral vertical lug back for ANSI/AGD mounting. When you visit the Dow-Gage web site (dowgage.com), you will be able to learn from the very designers, how to get the most out of this magnificent device. Also, you will notice that this store is asking $425.00 for what we are offering here for just 57.99 plus Shipping and $2.25 handling.As a token of appreciation for having you as our customer, we will send you, together with your item, 31 Morphy's principles to help you prepare people around you about the enormous convenience of having a helpful device capable of inspecting 100% at the speed the parts are produced or inspected. Such capability will allow you to deliver goods thru your door with a deep peace of mind, even if your customers apply a Zero Defects ( ZD) management-led program to sort out received defect goods from their suppliers. Priced to sell. Enjoy!

“Dow-Gage Inspection Bench for fast and accurate checking for mechanical parts. Good condition and working as intended.”

Type	Thickness
Model	10
Brand	Dow
Country/Region of Manufacture	United States
