Dpdt 10 Amp Ac & Dc Adjustable Slow Release (delay On Release) Time Delay Relay

US $24.99

Garden Grove, California, United States
Jan 29th

Open on mobile:
QR code

Up for auction is an estate find, DIVERSIFIED ELECTRONICS 10 Amp AC & DC Adjustable Slow Release (Delay On Release) Time Delay Relay. This relay is inside of its original box but it may have been previously used as it has the FINDER, 90.112, 11 pin 10A, 400VAC relay socket attached to it. You are bidding on the Diversified Electronics relay and the Finder socket together as pictured above. This item is guaranteed to work upon arrival or return it for a full refund (minus shipping). Flat rate shipping of $10.99 to the lower 48 states, including delivery confirmation. ~Good Luck!~ TDC/TUC SERIES On-Delay Relay Output DIMENSIONS INCHES OPERATION The time delay begins when power is applied to the input. Upon completion of the delay period, the relay energizes. Reset during or after the delay period is accomplished by removal of the input voltage. The TDC/TUC will not false transfer if voltage is removed prior to completion of the delay period. A fast recycle time permits accurate, high speed, continuous operation SUPPLY VOLTAGES: 24 or 120 VAC or VDC, 50/60 Hz; ±10% (TUC Series available in 120 Volts only) TIMING RANGES: Virtually unlimited. See page 101 for standard ranges available. TIMING TOLERANCES Minimum Setting: +0–20% Maximum Setting: ±10% REPEATABILITY: 1% maximum; no first cycle effect OUTPUT RATING: DPDT, 10 A @ 250 VAC or 24 VDC, resistive; 211 VA @ 120 VAC, inductive TEMPERATURES Operate: 32° to 131°F (0° to +55°C) Storage: -49° to 185°F (-45° to +85°C) RESET TIMES Before Time Out: 100 milliseconds After Time Out: 50 milliseconds RECYCLE TIME: 40 milliseconds FALSE TRANSFER: No REVERSE POLARITY PROTECTED: Yes POWER CONSUMPTION: 3 watts (approximately) DUTY CYCLE: Continuous LIFE EXPECTANCY Mechanical: 10 million operations (minimum) Electrical: 100,000 operations @ rated load DPDT, 10 Amp AC & DC Adjustable Slow Release (Delay On Release) Time Delay Relays

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Excellent condition, possibly unused”
