Dse Deep Sea Electronics Dse7410 Auto Start Control Module 7410 Diesel Genset

US $730

Forest Grove, Oregon, United States
Jun 8th

Open on mobile:
QR code

Deep Sea Electronics DSE7410 DC Generator Control Module The DSE7410 is a sophisticated mono display auto start control module packed with industry leading features to enhance single-set control. The module can be used across a wide range of diesel and gas gen-set applications. OVERALL SIZE - 240 mm x 181 mm x 42 mm (9.4” x 6.8” x 1.6”) PANEL CUTOUT SIZE - 220 mm x 160 mm (8.7" x 6.3") MAXIMUM PANEL THICKNESS - 8.0 mm (0.3”) WEIGHT - 0.88kg Key Features and Benefits: CAN and magnetic pick-up sensing Configurable inputs/outputs (11/8) Fuel usage monitor and low level alarms Remote communications (RS232, RS485, Ethernet, Modbus, RTU/TCP) Configurable event log (250) Integral PLC editor Load switching, load shedding & dummy load outputs Power monitoring (kW h, kVAr, kv Ah, kV Ar h), reverse power protection, kW overload protection Data logging (HDD/USB) DSE Configuration Suite PC Software Tier 4 CAN engine support Makes the module ideal for standard and electronic engine applications Provides multiple installation options Tracks the amount of fuel being used and sounds an alarm if over/under fuel use is detected Provides secure and simple off site monitoring. All ports are continuously active Provides access to historical alarms and operational status Ensures additional applications are easily integrated into the system Allows load options and dummy load requirements to be independently controlled Provides clear accurate power measurement information Provides current and historical status information Provides complete user-friendly configuration and easy-to-use high-level system control & monitoring Ensures the control module can be used with the latest in modern electronic engine technology Additional Features: Voltage measurement Dedicated load test button kW overload alarms Exercise timer Multiple language options Configurable timers & alarms Configurable start/stop timers Configurable maintenance alarms (3) Charge alternator failure alarm Backed-up real time clock DC Supply: CONTINUOUS VOLTAGE RATING - 8V to 35V Continuous CRANKING DROPOUTS - Able to survive 0V for 50 mS, providing supply was at least 10V before dropout and supply recovers to 5V. This is achieved without the need for internal batteries MAXIMUM OPERATING CURRENT - 260 mA at 12V, 130 mA at 24V MAXIMUM STANDBY CURRENT - 120 mA at 12V, 65 mA at 24V CHARGE FAIL/EXCITATION RANGE - 0 V to 35V Generator: VOLTAGE RANGE - 15V to 333V AC (L-N) FREQUENCY RANGE - 3.5 Hz to 75 Hz Outputs: OUTPUT A (FUEL) - 15A DC at supply voltage OUTPUT B (START) - 15A DC at supply voltage Magnetic Pick Up: VOLTAGE RANGE - +/- 0.5V to 70V FREQUENCY RANGE - 10,000 Hz (max) Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
