DSO150 Digital Oscilloscope full assembled with P6020 BNC standard prob G oq I, C $43.18 – Picture 0
DSO150 Digital Oscilloscope full assembled with P6020 BNC standard prob G oq I, C $43.18 – Picture 0

Dso150 Digital Oscilloscope Full Assembled With P6020 Bnc Standard Prob G Oq I

C $43.18

  • Shanghai, China
  • Aug 30th
Open on mobile:
QR code
Features: Adopt ARM Cortex-M3 processor (STM32F103C8), and include a 2.4-inch color TFT display screen. Used for secondary development on the basis of this kit, for example, it can be changed to Millivoltmeter, data loggers. Come with instructions, easy to install and operate. With Auto/Normal/Single trigger modes, easy to capture the moment waveform. Available rising or falling edge trigger. Observable previous waveform before trigger(negative delay). Can freeze waveform display at any time(HOLD function). With waveform parameter digital display, including frequency, period, pulse width, duty ratio, MAX./MIN./AVG./Peak-Peak/virtual values. Waveform storage function: will not lose the waveform after power off. Short-circuit and open-circuit detection: can help the user find out the soldering error. TFT controller recognition function. The SMD has been soldered, more suitable for electronic beginner. Specifications: Maximum Real-time Sampling Rate: 1MSa/s Analog Bandwidth: 0-200KHz Sensitivity Range: 5mV/div-20mV/idv Maximum Input Voltage: 50Vpk (1X probe) Input Impedance: 1M ohms/20pF Accuracy: 12 Bits Record Length: 1024 points Coupling Modes: DC / AC / GND Time Base Range: 500s/Div - 10us / Div Trigger Modes: Auto, Normal, and Single Trigger Position: Center of Buffer Supply Voltage: DC 9V(8-10V) Current Consumption:~120mA @ 9V Main Board Size: 94 * 65mm / 3.7 * 2.56in Analog Board Size: 65 * 47mm / 2.56 * 1.85in Screen Size: 52 * 40mm / 2 * 1.57in Package Size: 14.5 * 10 * 3.7cm / 5.7 * 3.94 * 1.45in Package Weight: 179g / 6.33oz Package List: 1 * Fully Assembled Oscilloscope 1 * P6020 Probe 1 * User Manual(English)On 30-Aug-21 at 17:34:15 EDT, seller added the following information:
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
GTIN Does not apply
MPN Does Not Apply
UPC Does not apply
Type see details
Brand Unbranded
