WELCOME TO OMEGA GLOBAL INCORPORATED ITEM FOR SALE DUPLO 4000 BOOKLET MAKER SYSTEM! ITEM FEATURES When it comes to high speed and ease of operation, nothing compares to the Duplo System 4000. This vacuum-feed collating and bookletmaking system offers professional printing operations a complete finishing solution designed to maximize productivity throughout the finishing process. Comprising a heavy-duty collator, dynamic bookletmaker, face trimmer and precision stacker, the System 4000 is capable of producing up to 4200 booklets or 10,000 collated sets per hour, and features the industry’s finest state-of-the-art feed system. In addition, its vertical design, modular styling and ability to handle a variety of paper types, sheet sizes and weights demonstrate superb versatility. C o l l a t o r Number of bins: 10, 20, 30, 40, 50 or 60 Paper Size (Min./Max.): 4.7” x 5.52” to 14” x 20” Paper Weight: 11 lb. to 12-pt. cover Bin Capacity: 2.5” Detection: Double feed, misfeed, paper jam, paper transport jam and bin empty Speeds: Bookletmaking - up to 4,200 sets per hour; collating - up to 10,000 sets per hour Feed System: Vacuum belt with air sheet separation Power Consumption: 120V 60Hz 9.5A Other Features: 5-digit display (ascending and descending); twin conveyor vertical paper transport; auto calibration; left or right exit selection; automatic bin selection; 4-step overlap controls; multi-step speed adjustment; block mode (1/2-block, 1/3-block and 1/4- block functions); interleaving sheet insertion; reject tray (right and left); and hand-marrying unit Connecting Devices: DC-48TW Trimmer, DC-48ST Stacker, DC-8000ST Rear Stacker, DC-12JR RearJogger, DBM-120 Bookletmaker, DBM-120T Trimmer, and System 4000 Kicker and Long Stacker Options: Document Integrity System and Intelligent Feeding System B o o k l e t m a k e r CORNER/SIDE/TOP STITCHING APPLICATION Sheet Size (Min./Max.): 4.73” x 5.51” to 13.82” x 14.41” Paper Capacity: Up to 30 sheets** SIGNATURE BOOKLETMAKING APPLICATION Sheet Size (Min./Max.): 4.5” x 6.6” to 14” x 20” Paper Capacity: Up to 25 sheets** GENERAL Speed: Up to 4,200 sets per hour* Detection: Jam and misfeed Number of Stitcher Heads: 1-4 (2 standard) Hohner heads Stitch Positions: Saddle, corner, side, none (fold only) Programmable Memory Settings: 8 Automatic Functions: Stitcher heads, back jogger, side guides, stitch stopper, fold stopper and fold-back stopper positions Power Requirements: 120V 60Hz 8A Other Features: Knife folder with six adjustable fold rollers and insert attachment for inserting loose sheets into booklets (i.e. 6-page newsletter). T r i m m e r Trimming Mechanism: Upper and lower shearing action Booklet Sizes (Min./Max.): 4.73” x 3.35” to 14” x 10” Trimmed Booklet Sizes (Min./Max.): 4.72” x 2.87” to 14” x 10” Trimming Margin: Up to 2.95” ** Cutting Thickness: Up to 50 sheets** Speed: Up to 4,200 sets per hour* Power Consumption: 120V 60Hz 8.5A Dimensions (L x W x H): 49” x 27.5” x 42” (with receiving tray) Weight: 442 lbs. Other Features: Jam detectors; adjustable belt in-feed timing; inter-locking safety covers; adjustable knife speed controlled on panel; auto knife up/down; optional extended conveyor and batch kicker; bypass for documents that do not need a face trim; trim/no trim; resettable output counter; compressed air to trimmings tray; trim scrap-box-full sensor; drop-away flap for trimmings, full-width head stop and spine compression ITEM DESCRIPTION UP FOR BID IS A DUPLO 4000 BOOKLET MAKER SYSTEM. UNIT INCLUDES DBM-400 DYNAMIC BOOKLET MAKER, DBM-400T TRIMMER, 2 X DC 1--60 COLLATORS (EVERYTHING IS LISTED IN THE NEXT "CONTENTS INCLUDED SECTION"). THIS ITEM HAS RECENTLY CAME OFF-LEASE AND WAS PULLED FROM A WORKING ENVIRONMENT. THE UNITS PHYSICAL CONDITION IS EXCELLENT. WE HAVE CONDUCTED TESTING OF THIS MACHINE AND THE UNIT IS IN GREAT WORKING CONDITION GUARANTEED! UNIT COMES WITH NON-DOA WARRANTY! UNIT WILL BE SHIPPED PADDED VAN TO INSURE ARRIVAL. CONTENTS INCLUDED HERE AT OMEGA GLOBAL INC WE TRY TO BE AS ACCURATELY DESCRIPTIVE AS POSSIBLE AND WANT OUR CUSTOMERS TO BE FULLY CONFIDENT THAT WHAT THEY ARE BIDDING ON IS EXACTLY WHAT THEY WILL BE RECEIVING. ALL ITEMS INCLUDED ARE EITHER LISTED HERE IN THE SECTION AND/OR ARE ALSO INCLUDED IN THE PICS. IF YOU DO NOT SEE IT IN THIS SECTION OR IN THE PICS THEN IT WILL NOT BE INCLUDED. ANYTHING LISTED IN THIS SECTION AND IN THE PICTURES IS WHAT YOU WILL RECEIVE. ANY ITEMS NOT RECEIVED THAT WERE LISTED AND/OR PICTURED, OMEGA GLOBAL INC WILL BE FULLY RESPONSIBLE FOR REFUNDING OR REPLACING THE MISSING ITEMS. ITEMS INCLUDED: DUPLO BOOKLET MAKER SYSTEM DUPLO DBM-400 DYNAMIC BOOKLET MAKER DUPLO DBM-400T TRIMMER 2 X DUPLO 10/60 COLLATORS MANUALS CONNECTING BRIDGE LIFTING UNIT LUL-HM 2 X DIAMOND PLATED STEP POWER CORDS SHIPPING · FREE SHIPPING TO CONTINENTAL U.S! All items will be shipped within 5-7 business days after payment is received. Most items are shipped next day after payment is received. NO LOCAL PICK UPS · Shipping charges are based on the size of equipment. Most items are shipped via UPS, USPS or Fedex, however larger items might require freight shipping and palletizing may cause delays in shipment times. · Express orders are available upon request. WARRANTY · The unit comes with a Non-DOA (dead on arrival) warranty. · Consumables are not guaranteed in any sale unless otherwise listed in the description section. · In the event of any damage in shipping or items not is condition as described, we OMEGA GLOBAL INC will be fully responsible for any charges in either replacing or repairing the unit in question or issuing a full refund once we have received the items back. · We OMEGA GLOBAL INC, are fully responsible for all reimbursements of items sold with any issues not listed in the ad, and/or cost of repairs or equipment. PAYMENT · We currently accepts all major credit cards; Visa, MasterCard, American Express, & Discover DIRECTLY and also through paypal. All payments must be made within 7 days from the winning bid date. An automated invoice will be emailed to the winner. Payments can be made by clicking on the Payment button. You then may choose to pay through PAYPAL or other accepted payment methods. · We also accept checks, cashiers checks, and wire transfers. TERMS · INTERNATIONAL BUYERS: Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Please check with your country's customs office to determine what these additional costs will be prior to bidding/buying. These charges are normally collected by the delivering freight (shipping) company or when you pick the item up – do not confuse them for additional shipping charges. · The customer is responsible for return shipping. All returned or exchanged items must be in same condition. Please inspect your purchase carefully. · All items we list on eBay are warranted against defect and DOA, unless listed as as-is in the warranty section. ABOUT US · OMEGA GLOBAL INC is a leading provider of quality New and pre-owned business equipment products ranging from medical, mailing, networking, end-of-lease, telecom, video, audio etc… to wholesale and corporate customers. OMEGA GLOBAL INC utilizes market knowledge and our expansive network of resources to offer a significant cost savings on discontinued or current products. OMEGA GLOBAL INC stock a wide range of high end products and stand behind our equipment and 5-star customer service.
