Duplo 500i Duetto Collator, Booklet System, Bourg

US $102,000.00

Oklahoma City, Oklahoma, United States
Jun 9th

Open on mobile:
QR code

Duplo 500i Duetto Collator and Booklet System. DSF-2200 SHEET FEEDER w/ PC CONTROLLER // DC-10/60i COLLATOR // DBM-500 PRO BOOKLETMAKER // DBM-500T TRIMMER New Machine Showroom Demonstrations 7163 Total sets ran. Total count in pictures taken from DBM-500 PRO Bookletmaker. We reserve the right to remove this listing at any time. The pictured machine is located in Oklahoma City. It will be for sale in our PFS showroom as well as here on eBay. Shipping: Free local pickup or ships to most commercial address's in the USA. We can also ship Internationally. Call or send an eBay message for quotes on shipping or any question regarding this piece of equipment, When comparing this unit on the web please know that. Print Finishing Systems is an authorized dealer of many lines of equipment including Duplo This unit is in great shape and has been completely gone through, cleaned and lubricated. by our factory trained and authorized technicians to insure trouble-free performance for many years to come. The 500i Booklet System is Duplo’s high production collating and bookletmaking system. Integrating the DSC-10/60i Suction Collators with the DBM-500 Pro Bookletmaker, the 500i Booklet System produces saddle, side, or corner-stitched applications at a production rate of up to 5,000 booklets per hour. Ideal for both offset and digitally printed applications, the 500i Booklet System offers enhanced features for optimum efficiency and productivity. PC CONTROLLER: 60-SECOND CHANGEOVERS--Automatically change over from a catalog to a CD-size booklet in under a minute using the PC Controller software. The PC Controller makes it incredibly simple for operators of any skill level to operate, program new jobs, and manage the settings of the entire system. The intuitive software guides operators step-by-step throughout the process and gives them complete control over the job parameters and adjustments to allow them to precisely set the stitch, fold, and trim positions. And with the ability to store virtually an unlimited number of jobs in the hard drive, users can instantly recall and change over jobs in less than 60 seconds! INTELLIGENT MULTI-BIN FEEDING--Perform custom feed applications and fulfill a variety of unique job requirements by using the IMBF (Intelligent Multi-Bin Feeding) feature that comes standard with the PC Controller software. Seamlessly merge black and white documents with color media, combine un-collated offset with collated digital output, and create one-to-one marketing booklets by inserting variable data material. Take full control of the feeding sequence, link bins, select the bins to feed from, and specify how many sheets to feed from each bin. With the IMBF, documents can also be delivered set-by-set or sheet-by-sheet into the bookletmaker. COLLATOR DC-10/60i The 500i Booklet System utilizes Duplo’s DSC-10/60i Suction Collators. The unique 8-belt air suction feed system along with an Air Management System make these collators the most reliable in the industry. Incorporating Duplo’s patented dual fan technology, each bin comes equipped with two individual fans – one to produce a stable flow of air for separation and the other to generate consistent suction for feeding. With adjustments conveniently located beside each bin, the Air Management System enables operators to easily fine-tune the amount and strength of air, if necessary. High resolution optical sensors add an extra level of reliability by ensuring miss or double feed errors are identified. Faulty sets are diverted into a reject tray to allow continuous operation and can easily be recovered by simply correcting and inserting them into the hand marry station. Optional ultrasonic sensors can be added for feeding sheets with heavy coverage. Ultrasonic sensors use sound waves instead of light, making them impervious to paper thickness, variations in ink, toner and coverage. The 500i Booklet System will be configurable with up to 6 towers for a total of 60 bins. The DSC-10/60i Collator offers flexibility for various application needs including Interleaf Modes to insert single or double sheets when stacking. 1/2, 1/3 and 1/4 block modes are provided for non-stop productivity. Specifications Number of Bins* 10, 20, 30, 40, 50, 60 (10 bins per tower)* Paper Size Width: 4.1” - 14” Length: 5.8” - 24” (width of paper must be within 7.88” - 9.05” when paper length is greater than 20”) Paper Weight Fine quality paper: 52 - 157gsm (Cover: 52 - 300 gsm) Art coated paper: 79 - 157gsm (Cover: 79 - 300 gsm) Bin Capacity 2.6” Speed Bookletmaking: Up to 5,000 sets/hour1 Collating: Up to 10,000 sets per hour1 Feed System Patented dual fan feed system for each bin Controller PC Controller w/IMBF or Color Touch Screen LCD panel (IMBF feature not available with LCD Panel) DBM-500 PRO BOOKLETMAKER After sheets are collated by the DSC-10/60i Collator, sets are delivered into the DBM-500 Pro Bookletmaker for stitching, folding, and trimming. Booklets can be saddle, side, or corner-stitched without additional tools required. The bookletmaker utilizes heavyduty Hohner stitch heads and can switch from 2 (standard) or 4 (optional) stitches as the job requires. Sheet sizes of 14” x 20” down to 4.75” x 7.01” can be processed with equal ease. Up to 25-sheet booklets can be processed for signature bookletmaking or up to 30 sheets can be processed for side or corner-stitching. With the 500i Booklet System, a wide range of applications can be produced and a number of options can be added to meet customer demands. Booklets can be face trimmed only with the DBM-500T Specifications CORNER/SIDE/TOP STITCHING APPLICATION Sheet Size (Min./Max.) 4.72” x 5.52” to 13.82” x 14.33” Paper Capacity Up to 30 sheets*** SIGNATURE BOOKLETMAKING APPLICATION Sheet Size (Min./Max.) 4.72” x 6.7” to 14” x 20” Paper Capacity Up to 25 sheets*** GENERAL Speed Up to 5,000 sets per hour** Detections Wire draw detection Number of Stitcher Heads 2 standard or 4 optional. Type: Hohner 43/6S Stitch Positions Saddle, corner, side, none (fold only) Programmable Memory Settings 12 Automatic Functions Stitcher heads, back jogger, side guides, stitch stopper, fold stopper, fold-back stopper positions, small booklet adjustments, fold roller gap, conveyance roller position, center reference, disengage the operator side stitching head when corner stitching DBM-500T TRIMMER Trimming Mechanism Upper and lower shearing action Booklet Size (Min./Max.) 4.72” x 3.35” to 14” x 10” Trimmed Booklet Size (Min./Max.) 4.72” x 3” to 14” x 10” Trim Margin Up to 1”** Speed Up to 5,000 sets per hour* Other Features Jam detectors; adjustable belt in-feed timing; inter-locking safety covers; automatic setting exit rollers; auto knife up/down; bypass for documents that do not need a face trim; trim/no trim; resettable output counter; compressed air to trimmings tray; trim scrap-box-full sensor; drop-away flap for trimmings; full-width head stop; spine compression; automatically adjustable in-feed roller gap DSF-2200 SHEET FEEDER w/ PC CONTROLLER • Compact and powerful • Feed tray selection for better tray optimization and feed flexibility • Processes up to 200 sheets (up to 300 gsm maximum paper weight)per minute depending on connected devices • Barcode Reader option allows for variable data processing and set integrity checking for sensitive information • Offers the same features as that of higher-end models • Maximum 14” x 20” paper size or 9.05” x 24” with optional Extention Tray Kit • User-friendly PC Controller allows operator full system control from one console • Equipped with ultrasonic feed detection and anti-static device for superior accuracy and flexibility to process wide range of stocks and printed media • Quantity of job memories limited only by size of hard drive Separation Front air (fan); side air (fan); optional trail edge (pump) Feeding System 8 belts with 40 square inches of suction (fan) Paper Loading Capacity Tray A 2.56” (65 mm) Tray B 7.87” (200 mm) Paper size Length 7.87” - 20” (200 - 508 mm) (Maximum paper length is 24” /610 mm only when the paper width is 7.88” - 9.05”/ 200 - 230 mm. If the width is more than 9.05”/230 mm, the maximum paper length is 20”/508 mm) Width 4.13” - 14.02” (105 - 356 mm) Paper Type Art/coated paper; laminated paper 79 - 300 gsm; ne paper 52.3 - 300 gsm Processing Speed Up to 200 sheets/minute (A4 SEF) Control Panel Liquid crystal display unit with main controls through PC interface Additional Functions Ultrasonic double-feed detection; end mark detector (sensor); anti-static device; alternate feed function ** Dependent upon connected devices and number of bins in use *** Dependent upon paper weight and size Oklahoma City, Oklahoma. 405-232-1750 Call or send an eBay message. We will be glad to answer any questions. Specifications COLLATOR DC-10/60i Power 120V 60Hz 7.9 - 8.4A 910 - 960W Dimensions (WxDxH) 34” x 33” x 78” Weight 674 lbs. BOOKLETMAKER DBM-500 PRO Power Requirements 120V 60Hz 6.5A Dimensions (LxWxH) 64” x 28” x 40” Weight 908 lbs. TRIMMER DBM-500T Power Requirements 120V 60Hz 10A Dimensions (LxWxH) 23” x 27.5” x 43” Weight 532 lbs DSF-2200 SHEET FEEDER w/ PC CONTROLLER Power Requirements 120 V - 60 Hz 2.6A 2.6 - 1.1A Power Consumption 260W Weight 300 lbs. Hand Marry Unit, LDR Bridge Unit and Step Approximate Weight 150 lbs. Production rates are based on optimal operating conditions and may vary depending on stock and environmental conditions. As part of our continuous product improvement program, specifications are subject to change without notice. Location and General Terms of Sale This machine is located in Oklahoma City. Print Finishing Systems. (PFS) is a new and used equipment dealer. We pride ourselves in handling every transaction professionally and ethically. Warranty All used equipment is sold "As Is" and "Where Is" unless otherwise stated. Shipping If you require a firm freight quote to anyplace in the world, please make your request by sending us an eBay message. We prefer to provide freight quotes to serious buyers that are willing to provide us their e-mail and physical address. We will also need to know if you will be receiving the freight at a (1) commercial or residential address, and (2) in the case of larger machinery, if you have a dock or forklift for receiving the freight (do you require a ground level delivery with a lift-gate?). Generally residential and lift-gate deliveries cost additional. (3) If you are considering a used piece of machinery, please know that in most cases a crating / packaging fee will apply. We ship domestically and worldwide by UPS, UPS Freight, FedEx, most common LTL carriers, and though special arrangement with private trucks. We are also very happy to ship with the carrier of your choice. If there is a safe and economical way to get the freight to you, we are happy to work with your source. Size & Weight is Approximate and on machine only. Final shipping weight will include crate,pallet and/or packaging materials. PFS eBay Sales: Used products for sale on eBay are not always from our primary lines that we are factory trained and authorized to service unless otherwise mentioned in the listing. With this said, we will make every effort to assist you with professional support in the purchasing process. We always encourage you to do your research and buy only machinery that will benefit you and your business. Our goal is to provide solutions. Feel free to call our sales staff with questions pertaining to your application. eBay Listing Specifications: We make every effort to provide proper listing specifications but in many cases we rely on internet and manufacturer based information, which is always subject to change. At times when selling product that is not one of our core product lines or an older product, we may not have correct information and so purchasers must do their homework and know what they are buying. If the purchase justifies a personal or 3rd party visit, please do so. Oklahoma Sales Tax: Sales tax will be added to Oklahoma sales based on destination county and city. Note: PFS Reserves the right to refuse sale to any buyers with excessive negative feedback left for sellers

“Very Lightly used for demonstrations on our showroom floor. Total sets ran 7163”

Brand	Duplo
Model	500i Duetto Booklet System
