Dwyer Instruments 641-12-led-nist Air Velocity Transmitter G5569444

US $549.00

Kingston, New Hampshire, United States
Jan 29th

Open on mobile:
QR code

DWYER - NIST The new Series 641 Air Velocity Transmitter is the ideal instrument for monitoring air flow. This transmitter uses a heated mass flow sensor which allows for precise velocity measurements at various flow rates and temperatures. The 641’s 16 field selectable ranges provides it the versatility to be selected for several air flow applications. The optional LED produces a COMPLETE, low-cost solution for local indication of air flow. Product Applications Exhaust Stack Flow Monitoring Air Control in Drying Processes HVAC Air Velocity Measurements Fan Supply and Exhaust Tracking CLEAN ROOM Fresh Air Supply Ensure Proper Lab Hood Exhaust Flow Rates Specifications Service:Clean air and compatible, non-combustible gases.Accuracy:3% FS Process gas: 32 to 122°F (0 to 50°C); 4% FS Process gas: -40 to 32°F & 122 to 212°F (-40 to 0°C & 50 to 100°C).Response Time:Flow: 1.5 seconds to 95% of final value (output filter set to minimum).Temperature Limits:Process: -40 to 212°F (-40 to 100°C). Ambient: 32 to 140°F (0 to 60°C).Pressure Limit:100 psi (6.89 bar) maximum.Humidity Limit:Non-condensing.Power Requirements:12-35 VDC, 10-16 VAC. 1.5 A rating required on supply due to initial power surge drawn by transmitter.Output Signal:4-20 mA, isolated 24V source, 3 or 4-wire connection.Output Filter:Selectable 0.5-15 (seconds).Loop Resistance:600 ohms max.Current Consumption:300 mA max.Electrical Connections:Screw terminal.Process Connections:1/2" male NPT.Enclosure Rating:Designed to meet NEMA 4X (IP66) for non LED models only.Mounting Orientation:Unit not position sensitive. Probe must be aligned with airflow.Weight:12.6 oz (357.2 g).Agency Approvals:CE. OPTIONAL DISPLAY VERSION:Display:4-1/2 digit 1/2" red LED.Resolution:1 FPM, 0.01 MPS (10 FPM @ 10,000 and 15,000 FPM ranges).Weight:13.3 oz (377 g).Features Ranges to 15,000 FPM or 75 MPS Bright LED Display Easy Push Button Set-up Compact Housing 4-20 mA Output Digital Filter for Signal Damping

Condition:

New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...

Brand

Dwyer Instruments
