Eaton Tandem 70553-rbm 25505-rsa Pressure Compensated Flow Piston Pump

US $3400

Houston, Texas, United States
Aug 27th

Open on mobile:
QR code

Up for auction is new tandem Eaton 70553-RBM pressure flow piston pump with bolt on Eaton 25505-RSA gear pump. I will list specs below for each pump. Please note these are brand new open box Eaton pumps but will not include warranty, hence why fraction of the price! This specific setup is over $9k from Eaton with 24 week lead time! Here below are the specs…. Eaton 70553-RBM Feature Code Description CODE TITLE AAW 69 CM3/R [4.21 IN3/R] PRESSURE COMPENSATED/ PRESSURE FLOW COMPENSATED PISTON PUMP INPUT SHAFT ROTATION R RIGHT-HAND ROTATION (CW) INPUT SHAFT AA 14 TOOTH 12/24 SPLINE, SHAFT EXT 55.6 [2.19] PRESSURE COMPENSATOR SETTING 01 206.8-213.7 BAR [3000-3100 LBF/IN2] FLOW COMPENSATOR SETTING 01 13.10-14.47 BAR [190-210 LBF/IN2] COMPENSATOR SPECIAL FEATURES 0 TOP MOUNTED COMPENSATOR ASSY, NO SPECIAL FEATURES MAIN PORT SIZE & LOCATION A SIDE PORTS; PRESSURE - 1.00 SAE 4-BOLT SPLIT FLANGE PORT STANDARD PRESSURE SERIES (CODE 61); SUCTION - 2.00 SAE 4-BOLT SPLIT FLANGE PORT STANDARD PRESSURE SERIES (CODE 61) DRAIN PORT SIZE & LOCATION A .875-14 UNF-2B SAE O-RING PORT - LEFT SIDE AUXILIARY (REAR) MOUNTING FEATURES B [2-BOLT B] SAE FLANGE SERIES 101-2 WITH A 13 TOOTH 16/32 EXT SPLINE MAXIMUM DISPLACEMENT OPTION 0 STANDARD DISPLACEMENT (AS GIVEN IN CODE TITLE) SPECIAL FEATURES 00 NO SPECIAL FEATURES PAINT 0A PRIMER PER SPEC 209-13A IDENTIFICATION 0 STANDARD DESIGN CODE B COMPENSATOR UPGRADE Eaton 25505-RSA GENERAL SPECIFICATIONS PRODUCT NAME Eaton Series L2 Gear Pump CATALOG NUMBER MODEL CODE ABFAR05AA01000000000A0A PRODUCT LENGTH/DEPTH 7.33 in PRODUCT HEIGHT 6.47 in PRODUCT WIDTH 7 in PRODUCT WEIGHT 15 lb PRODUCT SPECIFICATIONS SPECIAL FEATURES None CONFIGURATION Single UNIT TYPE Plain MINIMUM CONTINUOUS OIL VISCOSITY 45.5 SUS INTERMITTENT PRESSURE - MAX 4000 Psi IDENTIFICATION Standard DESIGN CODE A WORKING TEMPERATURE - MIN -20 °F HOUSING MATERIAL Aluminum AUXILIARY MOUNTING FEATURES (REAR) None PAINT Primer Per Spec 209-13A DISPLACEMENT 42.8 cm/rev PORTS SIZES, LOCATIONS AND BACKPLATE - (SINGLE UNIT) Plain, Suction Port 1.625-12 UN-2B SAE O-Ring Port; Pressure Port 1.0625-12 UN-2B SAE O-Ring Port - Side Ports CONTINUOUS WORKING TEMPERATURE - MAX 225 °F SHAFT ROTATION Right TEST DATA Generic INPUT SHAFT 13 TOOTH 16/32 SPLINE, SHAFT EXT 41.1 [1.62] CONTINUOUS PRESSURE - MAX 3600 Psi APPLICATION Agricultural, Civil Engineering, Primary metals, Material handling, Speciality Construction, Metal Forming, Natural Resources

Condition:	New – Open box: An item in excellent, new condition with no functional defects. The item may be missing original packaging and may have been used for testing or demo purposes. The item includes accessories found with the original product and may include a warranty. See the seller's listing for full details and description. ...	Brand	Eaton
MPN	Does Not Apply
