Eight 8 Way Channel Relay Io Module Board Control 12v Hr1208b04x2 Negative Logic

US $31.99

Union City, Georgia, United States
Jan 29th

Open on mobile:
QR code

You are bidding on 1 pc HIVITRONIX 8 CHANNEL WAY RELAY I/O CONTROL BOARD PIC, AVR, 8051 PROJECT MODEL HR1208B4X2 We are listing this version due to our customer requests who have enjoyed our high quality I/O boards. This relay control module/board requires a 0V input to activate each channel. Some industrial applications have open collector transistor outputs to switch external device like outputs from remote camera controllers. Other applications have passive microswitch or solid state switch output to ground. If your application requires a negative logic or 0V to switch a relay channel, then this I/O relay board is for you. This auction is for 12V applications. FEATURES Compact and packed with features. We have you in mind when designing this board. Board can be extended from 8 channels to 16 channel applications. Power supply is extensible. No need to power a second board for a 16 channel. Simply connect at the power link. All input and output connections are clearly marked. 8 output red LEDs. ON/OFF Green Power LED. Power input terminals are physically isolated from signal terminals. Mounting holes on board for industrial/commercial application. Great for schools project, research and development. INPUTS (@25 deg. C typ.) NUMBER OF INPUTS: 8 TYPE: 10 terminal/input. 8 x 1 way + 2 x GND. 8 signals + 2 Gnd. Gnd (-) . Gnd is common to all 8 inputs. STRIP LENGTH: 7.5 mm WIRE: 2.5mm2 (Solid), 1.75 mm2 (Flexible), AWG 22 - 12. SIGNAL VOLTAGE LEVEL : 0V (typ0. Any 0VDC, N/O contact, or open collector input will activate each channel. Since these are NEGATIVE LOGIC inputs, a signal voltage of +12V will disable each channel. Must have common ground connection with controlling board/device/equipment. OUTPUTS(@25 deg. C typ.) NO. OF OUTPUTS: 8 x 3 way connector TERMINALS: Normal Close (NC), Normally Open (NO), Common (C). Independent. SWITCH: Songle Relay Model SRD-12VDC-SL-C LOAD CAPACITY: 10A 250VAC, 10A 125VAC, 10A, 30VDC. VISUAL: 8 x 5mm Red LEDs standard. (may vary). Indicate if you prefer Green LEDs. DIMENSION 112mm (L) x 90mm (W) x 20 mm (H max.) 4.20 in (L) x 3.54 in (W) x 0.8 in (H max.) 4 mounting holes at 91 mm x 78 mm POWER SUPPLY REQUIREMENT The board requires a power supply of 12VDC (nominal) VOLTAGE, V = 12VDC CURRENT, I = 6mA (NL), 270mA (FL) POWER , P >= 4W PAYMENT Paypal, or Credit (Visa, MasterCard, Discover) via Paypal SHIPPING Worldwide FREE domestic USA shipping. Worldwide shipping depends on buyer's location. Ships 1-2 days after payment confirmation Comes with delivery confirmation Comes packaged in anti-static bag RETURN Return acceptable on this item within 7 days. Buyer responsible for all shipping charges. If you have any question, ask before buying/bidding. Be sure to add us to your favorites list! For other high quality I/O boards Check Our Store: Hivitronix or check out my other items! We are stocking new items daily, so be sure to check back daily. http://i.ebayimg.com/10/!B-TERMw!mk~$(KGrHqIOKpIEy+jC)oKTBM8UhWhGjQ~~_0.JPG Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items. Froo www.froo.com | Froo Cross Sell, Free Cross Sell, Cross promote, eBay Marketing, eBay listing Apps, eBay Apps, eBay Application

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Hivitronix
Model	HRxx08
Type	Relay Module
MPN	HR1208B04X2
Country of Manufacture	United States
Country/Region of Manufacture	United States
