Eimac Yu-191-b High-mu Water Cooled Power Triode

US $250.00

Colorado Springs, Colorado, United States
Jun 9th

Open on mobile:
QR code

MFG: CPI-EIMAC MODEL: YU-191-B SERIAL NUMBER: UHG0038 REVISION: 0340 DATE CODE: 0332 DISCRIPTION: The EIMAC YU-191B is a ceramic/metal, water cooled, high-mu triode intended for use as an amplifier, oscillator, or modulator, or in voltage regulator applications. Its maximum rated anode dissipation is 7000 watts. Operation with zero grid bias in many applications offers circuit simplicity by eliminating the bias supply. Grounded grid operation is attractive since a power gain of over 20 times can be obtained. The YU-191B is identical to the YU-191A, except that it uses a more efficient and rugged cooler on the anode. ELECTRICAL Filament: Thoriated Tungsten Voltage ..............................................7.5 ± 0.37 V Current @ 7.5 volts ................................... 51.5 A Amplification Factor, Average ........................... 160 Direct Interelectrode Capacitances (Grounded Filament)2 Cin ............................................................... 38.0 pF Cout............................................................... 0.6 pF Cgp.............................................................. 24.0 pF Direct Interelectrode Capacitances (Grounded Grid)2 Cin ............................................................... 38.0 pF Cout............................................................. 24.0 pF Cpk ................................................................ 0.6 pF Frequency of Maximum Ratings (CW) .............. 110 MHz MECHANICAL Maximum Overall Dimensions: Length ............................................... 9.8 in; 248 mm Width ............................................... 7.1 in; 180 mm Net Weight...................................................5.5 lb; 2.5 kg Operating Position................. Vertical, Base Up or Down Maximum Operating Temperature: Envelope and Ceramic/Metal Seals................ 250°C Cooling .................................................................. Water Base ....................................................... Special Coaxial Characteristics and operating values are based upon performance tests. These figures may change without notice as the result of additional data or product refinement. FOR FULL DATA SHEET PLEASE VIEW: http://www.rell.com/filebase/en/src/Datasheets/YU191B.pdf **TESTED GOOD, WORKING CONDITION.**

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	EIMAC
MPN	UHG0038
Model	YU-191-B
