Electric Fence Charger

US $45.00

Isle of Palms, South Carolina, United States
Jan 30th

Open on mobile:
QR code

Electronics : Electric Fence THIS DEVICE IS NOT UL APPROVED. This is a 'Home Power' circuit from Richard Perez powered by low voltage (12) direct current. This circuit uses two 555 timer IC's to create pulses. The first timer, U1, is operated astable as an oscillator. U1 determines how often the pulses will be generated. The second timer determines the duration of the pulse. U2 is operated as a slave to U1. U2 only emits a pulse when U1 says to do so. U2 is a monostable multivibrator also known as a "one-shot" multivibrator. The output stage is made by 2 transistors: the 2N222A and the 2N3055. The 2N3055 is connected to the ignition coil of a car. The exact automotive ignition coil you use is not important. In order to function properly every electric fence needs a good ground. Consider several grounding rods if your soil is dry. Drive the rods as far as you can into the ground and use at least 8mm wire between the charger and the ground rod. Usage: If you are training livestock to an electric fence, then keep the frequency high. After the livestock is wary of the fence, turn the frequency down to save power. You can adjust the amount of power to suit your ground conditions (dry ground has higher resistance and requires more power). You can adjust the power to suit the length of your fence. It's possible to charge up over five miles of fence in dry conditions. CAUTION: THIS ELECTRIC FENCE MAKES HIGH VOLTAGE The basics of safety apply here. Don't let your body get between the high voltage output of the coil and ground. Turn the fence OFF if you are doing repairs. The pulse emitted by the electric fence is high in voltage, but limited current. THIS DEVICE IS NOT UL APPROVED.

Condition	New other (see details) : A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“New item just built.”
