Electrodata Ats 2 Test Set

US $400.00

Houston, Texas, United States
Jun 9th

Open on mobile:
QR code

ATS 2 Enhanced Audio Test Set Contact Electrodata at 1-800-441-6336 The ATS 2 is a full-featured audio test set in a portable, hand-held unit. The set facilitates the installation and maintenance of leased or dial-up circuits and equipment connected to the public switched networks. Designed to comply with IEEE and Bell specifications, the ATS 2 performs all basic analog transmission measurements plus Impulse Noise, Signal-to-Noise and P/AR tests. The ATS 2 can also function as a telephone handset on 2- and 4-wire circuits, with dial, hold, talk and listen capabilities. Menu driven Impulse Noise and Signal-to-Noise tests DTMF or pulse dialing MF dialing optional Tests to IEEE and Bell specifications Specifications for the ATS 2 SEND MODES QUIET TERMINATION Signal generator disconnected from output Output noise: Less than 10 dBm SEND FREQUENCY Range: 50 Hz to 5 kHz Resolution: 1 Hz Accuracy: ±0.03% Direct entry: Numeric keypad Stepping: ±1, 10 and 100 Hz Fixed frequencies: 1004 Hz, 2713 Hz and programmable auxiliary tone Slope tones: 404 Hz, 1004 Hz and 2804 Hz, 10 seconds per tone Auto step: Programmable start, stop, step size and step duration P/AR signal: 16 phase related frequencies Distortion: 50 Hz to 200 Hz less than -45 dB 200 Hz to 5 kHz less than -50 dB SF skip: 2450 Hz to 2750 Hz SEND LEVEL Range: ±10 dBm to -50 dBm (0 dBm maximum for P/AR) Resolution: 0.1 dB ACCURACY 50 Hz to 200 Hz: ±0.5 dB 200 Hz to 2 kHz: ±0.2 dB 1004 Hz: ±0.1 dB from 0 to -19 dBm Direct entry: Numeric keypad Stepping: ±0.1 and 1 dB FLATNESS 50 Hz to 200 Hz: ±0.5 dB 200 Hz to k5kHz: ±0.2 dB MEASURE MODES LEVEL/FREQUENCY Level Range: +10 dBm to -65 dBm Resolution: 0.1 dB ACCURACY 50 Hz to 200 Hz: ±0.5 dB 200 Hz to 5 kHz: ±0.2 dB 1004 Hz: ±0.1 dB from 0 to -19 dBm Detector: Averaging Display modes: Absolute or relative with respect to input level Frequency range: 20 Hz to 10 kHz Resolution: 1 Hz Accuracy: ±1 Hz BACKGROUND NOISE Range: 10 dBm to 99 dBm Resolution: 1 dB ACCURACY 20 dBm to 99 dBm: ±1 dB 10 dBm to 20 dBm: ±2 dB Filters: C-Message, 3 kHz flat, C-Notch Detector: True RMS Display Modes: Absolute or relative with respect to input level Notch filter: 995 to 1025 Hz greater than 50 dB rejection Loss of tone: Less than -40 dBm SIGNAL TO NOISE Signal range: +10 dBm to -40 dBm Noise range: 10 dBm to 90 dBm Ratio range: 10 to 50 dB Resolution: 1 dB Accuracy: ±1 dB Detector: Average for level and true RMS for noise Display modes: Absolute or relative with respect to current measurement Notch filter: 995 to 1025 Hz greater than 50 dB rejection Loss of tone: Less than -40 dBm IMPULSE NOISE Threshold range: 30 dBm to 100 dBm Resolution: 1 dB Accuracy: ±1 dB Count rate: 7 per second Count timer: 1 to 99 minutes or continuous Count range: 0 to 9999 Filters: C-Message, 3 kHz flat, C-Notch Notch filter: 995 to 1025 Hz greater than 50 dB rejection Loss of tone: Less than -40 dBm Loss of tone counter: 0 to 9999 P/AR RATING Range: 0 to 120 P/AR units Resolution: ±1 P/AR unit ACCURACY 30 to 110: ±2 P/AR units 0 to 120: ±4 P/AR units Input level range: 0 to -40 dBm Detector: Average DIAL MODES MANUAL DIAL Dial method: DTMF or pulse with optional MF DTMF signals: Full supervisory tone set, including A, B, C and D Redial: Up to last 16 digits AUTODIAL Memory: 10 locations, each capable of holding up 16 digits Dial Method: DTMF or pulse with optional MF DTMF signals: Full supervisory tone set, including A, B, C and D GENERAL INPUT/OUTPUT Line: 2-wire or 4-wire Connectors: RJIIC modular jack and dual miniature phone jack (0.173" diameter on 0.312" centers, mates with ADC PJ777 or Switchcraft TT253) DC blocking: 150 volts Normal/Reverse switch: Reverse send and receive Hold circuit: Electronic, 24 ma. Impedance: 600 or 900 ohms Termination: Bridge or terminate Bridging loss: Less than 0.2 dB Return loss: Greater than 30 dB Longitudinal balance: Greater than 80 dB at 60 Hz Greater than 70 dB at 540 Hz Greater than 60 dB at 4 kHz Decreasing 6 dB per octave above 4 Hz POWER Batteries: Rechargeable nickel cadmium Battery life: 6 hour minimum per charge, one-half hour minimum after battery low indication Recharge time: 4 hours maximum, with unit turned off AC operation: 115/230 vac, 50/60 Hz Auto shut-off: 15 minutes after last key depression PHYSICAL Push-to-talk: Built-in condenser microphone Monitor: Adjustable volume, switchable between send and receive Display: 2 line by 16 character, LCD

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“In perfect working condition”
