Elenco Surface Mount Generator Kit - Fg600k

US $5400

Chatsworth, California, United States
Nov 17th

Open on mobile:
QR code

Elenco Surface Mount Generator Kit - FG600K Product description Provides a constant source of DC voltage and current powering and testing electronic devices in place of a battery Single output supplies a fixed voltage of 1.5V, 2.2V, 3V, 4.5V, 5V, 6V, 7.2V, 9V, 10V, 12V, 13.8V, or 15VDC and current up to 1 amp Maintains output voltage within 0.2V when going from no load to a 1-amp load Output voltage will not increase while the output voltage settings are being adjusted Accepts input voltage of 120VAC at 60 Hz Solid state DC power supply - an ideal bench top battery eliminator Voltages are conveniently selected by a rotary switch, precisely set by using 1% resistors Output is fully protected from short circuits and overloads Provides both line and load regulation of the output voltage For 30 years Elenco has been using their strong engineering and design skills to develop reliable, affordable electronic test equipment, tools, and educational kits The Elenco XP-100 single-output battery eliminator and DC power supply provides a constant source of DC voltage and current for powering and testing electronic devices. It can be used in place of most batteries, including AA, AAA, C, D, and 9-volt types. The power supply unit (PSU) has one output that supplies a fixed voltage of 1.5V, 2.2V, 3V, 4.5V, 5V, 6V, 7.2V, 9V, 10V, 12V, 13.8V, or 15VDC and current up to 1 amp. An integrated circuit (IC) holds output voltage within 0.2V when going from no load to a 1-amp load, and the output voltage will not increase while the output voltage settings are being adjusted. The PSU accepts an input voltage of 120V AC at 60 Hz, and a 2-amp fuse and thermal cutoff circuit help protect against short-circuits and overload. Specifications Number of outputs 1 Maximum voltage and current output Voltage: 15VDC; Current: 1 amp Accuracy + or 5% of reading Line regulation 105V to 135 VAC Load regulation 0.2V (max) when going from 0 to 1 amp Ripple 0.005V RMS (root mean square) at rated current Input impedance 0.025 ohms Power requirements 120VAC at 60 Hz Weight 5lb. Dimensions 3-3/4 x 8-1/4 x 7 inches (H x W x D) H is the vertical distance from lowest to highest point, W is the horizontal distance from left to right, and D is the horizontal distance from front to back. Power supply units (also known as PSUs, AC power supplies, DC power supplies, and battery eliminators) provide AC or DC voltage to power or test devices such as tools, appliances, and electronicponents. The PSU draws energy from a line source such as a wall socket and converts it to a constant, specified amount of voltage or current that is then outputted to a connected device. In general, a power supply unit will be classified as either a linear PSU (also known as a linear regulation or line-frequency PSU) or a switched PSU (also known as a switching-mode power supply, SMPS, or switcher). Typically, a linear PSU has a simpler design and provides a faster transient response time and less electrical interference and noise than a switched PSU. A switched PSU is often smaller, lighter, and more efficient than a linear PSU and generates less heat. The transient response time of a PSU indicates how quickly the PSU can resume the desired constant output after a sudden change in input. Ripple voltage or current indicates how much unfiltered noise and AC voltage or current is present at the output of a filtered power supply operated at full load. The temperature coefficient is the percent average change in output voltage per degree centigrade of change in ambient temperature. Fuses, current limiters, and other forms of overload protection can be built into the PSU to help protect against voltage spikes or short-circuiting. Elenco Electronics manufactures test and measurement equipment for telmunications, electronics, and engineering applications, as well as educational products. Thepany, founded in 1972, is headquartered in Wheeling, IN. From the Manufacturer Deluxe Battery Eliminator Model XP-100 - A solid state DC power supply designed to be an ideal bench top battery eliminator and substitute for a wide variety of the most popular batteries including AA, AAA, C, D and 9 volt types. The voltages are conveniently selected by a rotary switch and are precisely set by using 1% resistors. A special IC circuit keeps the output voltage within .2V of setting when going from no load to one ampere and the output is fully protected from short circuits and overloads. Advanced, solid-state electronics provide both LINE and LOAD regulation of the output voltage. The voltage selector switch is precision-designed so that the output voltage does not increase during adjustment between voltage ranges. Specifications: Input Voltage - 120VAC, Output Voltage - 1.5, 2.2, 3, 4.5, 5, 6, 7.2, 9, 10, 12, 13.8, 15VDC , Output Current - 1A max, Accuracy - 5%, Dimensions - 3 3/4" (H) x 8 1/4" (W) x 7 " (D), Weight - 5 lbs. Shipping *Shipping is Free! Most items will be shipped within 24 hours after payment has been received and/or cleared. A tracking number will be provided for all shipments/orders. *Free shipping applies to the lower 48 States only. Extra fees may apply for items shipped to Alaska, Hawaii, and US Territories. Payment Through PayPal we accept all Major Credit Cards: Visa, MasterCard, Discover, American Express, and E-Checks. Sales tax of 9.0% will be charged for all California buyers. Returns If for some reason you are not satisfied with your purchase please email us within 30 days of receiving, for a return. We will issue a RMA number and directions on how to complete the return. Please do not send anything back to us without an assigned RMA number. All non-authorized packages will be refused. All returning item/(s) must be in original new condition with all original packaging and accessories or a 20% restocking fee will apply. Shipments Damaged by Delivery Carrier If you receive your package and the item is damaged, buyer must contact us within 3 business days of delivery. We will set up a claim with the carrier and send you a replacement. If an item is not available for replacement, we will issue you a full refund. Please allow up to 7 business days for a refund to be credited. Contacts All email inquires will be answered within 24-48 hours. Office Hours: Monday - Friday 8:30 A.M - 4:30 P.M PST Closed on Saturday, Sunday and all major Holidays.
