ELMO OCA-5/60 Current Mode DC Servo Amplifier, US $3100 – Picture 0
ELMO OCA-5/60 Current Mode DC Servo Amplifier, US $3100 – Picture 0

Elmo Oca-5/60 Current Mode Dc Servo Amplifier

US $3100

  • New Taipei City, Taiwan
  • Jun 9th
Open on mobile:
QR code
Ocarina-Current Mode Servo Amplifier  Ideal for DC brush and brushless for trapezoidal commutation The OCA-5/60  is a series of miniature current mode servo amplifiers for DC brush and trapezoidal brushless motors. Although extremely compact, the Ocarina can support up to 10 amps continuous current. This high power density servo amplifier can deliver up to 2800 W of peak power or 1400 W of continuous power in a matchbox size package weighing only 1.6 oz  (45 g). The servo amplifier offers significant operating features, including excellent output linearity and zero dead band performance. The Ocarina is a PCB mounted device that enables efficient, cost saving implementation. Highlights  • Operates in current mode  • 0 ~ 59 VDC isolated DC power source for 60 V models  • 0 ~ 95 VDC isolated DC power source for 100 V models  • Zero deadband  • Excellent linearity  • Differential current command input  • Motor current monitor  • Current gain change for low inductance motors  • Status indication by four open collector optos  • External continuous and peak current-limit adjustments  • Interface via 2 mm pitch 0.51 mm square pins  • Package: plated AL 6063T5 with electroless nickel, plastic housing, UL94V0 recognized (Ocarina only)  • Ultra-compact size – Ocarina: 2.1" x 0.6" x 1.8" (55 x 15 x 46.5 mm) • Weight: Ocarina – 1.6 oz (45g) Model: OCA-5/60 Net weight 45 g (1.6 oz) Gross weight 80 g (2.8oz) Product Dimensions 55 x 15 x 46 mm (2.1"x 0.6" x 1.8" in) Package Dimensions 90 x 72 x 41 mm ( 3.5" x 2.8" x 1.6" in)
