Entegris Es-1c-at-xx Autotune Single Channel Control Module & Sensor Probe

US $172.49

West Chester, Ohio, United States
Jan 30th

Open on mobile:
QR code

Item: Espy® AutoTune Single Channel Control Module ES-1C-AT-XX, New in Factory Packaging with 20M sensor! • Quickly and easily calibrate the module with a push of the membrane button switch. • Microprocessor-based design enhances performance and reliability by adjusting for physical and environmental changes affecting the dielectric of the media and/or surroundings, such as slurry build-up on tubing walls. • Two LEDs provide status indication and system alarming conditions. • Numerous configurable outputs provide flexibility. LOCATION: PALLET D BOX 34 Specifications Physical Specifications Enclosure material: glass-filled polypropylene Enclosure rating: NEMA 1 Mounting requirement: 35 mm DIN rail Dimensions, hardware: 2.65" x 0.80" x 3.06" Weight: 2.0 ounces Electrical Specifications Operating voltage: 10 VDC to 30 VDC Supply ripple: 0.5 Vp-p maximum Operating current: 70 mA maximum Alarm output configuration: 1 NO or NC output, PNP or NPN Cable break output configuration: 1 output, NC, PNP or NPN Output configuration selection: push button programmable Output voltage drop, NPN: 1.2 VDC maximum Output voltage drop, PNP: 1.2 VDC maximum Rated output load: 50 mA resistive maximum Output current leakage: 10 mA maximum Operating temperature: 10°C to 55°C Operating humidity: 0% to 95% RH, non-condensing Capacitance range: 0 pF to 30 pF Remote sensor cable length: 0.5 meters to 20 meters Sensitivity, 3m cable: 1.0 pF Sensitivity, 10m cable: 1.0 pF Sensitivity, 20m cable: 1.0 pF Response time: 75 mSec Reverse polarity protection? yes Output overload protection? yes Environmental compensation: option (programmable) Temperature compensation: internal Calibration: automatic using push button Indicators: red LED alarm; green LED power and cable break Electrical connections: 4 screw terminals, one 3 pin panel mount connector CE rating: EN50081-1 1992, 50082-1 1997

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Entegris
MPN	2493
Model	ES-1C-AT-XX
Serial Number	01153
