Ep4ce10f17c8 Altera Cyclone4 Cy7c68013a Fpga+usb2.0 High Speed Development Board

US $85.50

Tianjin,300162,TianJin, China
Jun 9th

Open on mobile:
QR code

Product description: Altera cyclone-4 FPGA+USB2.0 module can be easily. used to realize the high-speed data transmission between the FPGA and PC or other host computer, and at the same time, designed to be used as core module for bigger design. This development board is designed by using FPGA + USB, FPGA chip using EP4CE10F17C8 chip of Altera company’s Cyclone IV E series. USB chip use USB2.0 high-speed chip CY7C68013A of Cypress company . [about chips and components] The general view: 1. User Port: 2.54mm pin pitch header, a total of 85 I\O pins. Meet the bigger design. 2. EP4CE10: BGA256 package, the resources as shown below: 3. SDRAM: H57V256, two memories of 256Mbit SDRAM on board, single chip of data width is 16bit, two slices is 32bit. 4. AS interface: the FPGA program download and debug interface. 5. JTAG interface: the FPGA program download and debug interface. 6. Memory: 16 Mbit serial Flash memory. The FPGA configuration program memory. 7. Oscillator: 48MHZ Oscillator. 8. USB firmware memory: AT24C64,2-wire serial EEPROM, 64K (8192 x 8)bits. 9. Mini USB interface: PC connection interface, the USB program download and debug interface. 10. CY7C68013A: QFN56 package, single chip integrated USB2.0 transceiver , Smart SIE, and Enhanced 8051 Microprocessor. 11. LM75A: Digital temperature sensor, high resolution of 0.125°C. 12.DC 5V power input interface; power switch. 13. Reset button of FPGA. 14. Protection circuit: 6.2V voltage protection; 300ma FUSE Self-recovered safety. 15. SDRAM: H57V256, two memories of 256Mbit SDRAM on board, single chip of data width is 16bit, two slices is 32bit 16. Power management chip: AMS1117,1.2V,2.5V,3.3V. 17. High quality filter capacitance resistance: to ensure the input and output stable and reliable. Rate:More than 30Mbyte speed the actual test, transmission speed will be based on PC configuration is . Package including: 1pcsxFPGA board In addition,when you received the goods,please contact me,I send the schematic to you via email. Other parts you can order for this board: USB-Blaster: http://www.ebay.com.hk/itm/171172360528?ssPageName=STRK:MESELX:IT&_trksid=p3984.m1558.l2649 USB Cable: http://www.ebay.com.hk/itm/171173166348?ssPageName=STRK:MESELX:IT&_trksid=p3984.m1558.l2649 DC 5V1A Adapter: http://www.ebay.com.hk/itm/171173064678?ssPageName=STRK:MESELX:IT&_trksid=p3984.m1558.l2649 Shipping & Handling: The default shipping is by China Post air mail/Hongkong air mail. Item will be shipped within 2-3 working days after full payment is received. The delivery to most of the countries will take 2-4 weeks, if there's no problem when pass through the customs. It will take about 30 days or more to some places like South America,India,Mexico and Africa. We only ship to the approved address given in PayPal payment. Please make sure payment address in PayPal is correct. Any non-received items caused by invalid address registered on PayPal are not in our full refund or replacement policy. The extra fee occured when the product pass through the customs should be paid by buyer Return & Refund policy: We accept Paypal as the payment method. If you can't receive the product within 2 months (60 days), please contact with us,we promise to payback 100% of your money. We ensure our products work normally before post.If the products is broken before arrival to you,all you should do is taking a photo to show us our broken product.We promise to payback 100% of your money.
