ESSEX Magnet Wire 28 AWG Gauge Enameled Copper 5.5 lb 200C Coil Winding, US $100.00 – Picture 0
ESSEX Magnet Wire 28 AWG Gauge Enameled Copper 5.5 lb 200C Coil Winding, US $100.00 – Picture 0

Essex Magnet Wire 28 Awg Gauge Enameled Copper 5.5 Lb 200c Coil Winding

US $100.00

  • Harrison, Tennessee, United States
  • Aug 19th
Open on mobile:
QR code
ESSEX BRANDED 28 AWG MAGNET WIRE PARTIAL SPOOL GROSS WEIGHT 6 POUNDS 2.6 OZ SO I'M GUESSING AT LEAST 5.5 POUNDS OF WIRE SPECIFICATIONS FROM ESSEX: Nominal Diameter: 0.0144 inch GROSS DIAMETER WITH INSULATION:  0.015 inch as shown  Nominal OHMS/LB. -20 Celsius: 129.9 Feet/LB: 1988 Magnet Wire Technical Specifications: Conforms to MW-35C, UL recognized Class 200 High temperature Class: 200°C (392°F) Magnet Wire AWG size: 28 AWG, round Insulation type: modified polyester basecoat and an improved polyamideimide topcoat Insulation build: heavy build, more durable than single build Magnet Wire Applications: Wind Generators Fractional and Integral HP Motors Hermetic Motors DC Motors Power Tools Automotive Alternators and Generators All Dry Type Transformers, Class 105 through 200 Electronics, All Types of Coils, Class 105 Through 200 Arts & Crafts This type of Essex magnet wire is the standard of comparison for magnet wire performance in virtually every severe and heavy duty application. The combination of a modified polyester basecoat and an improved polyamideimide topcoat results in an insulation system with outstanding physical toughness, excellent dielectric properties, and superior chemical resistance to most common solvents and refrigerants. Windability of this type of Essex magnet wire, verified by years of experience on virtually every type of winder, has always been excellent. Improvements in the topcoat have resulted in a product that is even more superior with regard to high slot fill and insertability.
“SPOOL HAS DAMAGE, WIRE IS FINE.”
Country/Region of Manufacture United States
Brand Essex
Sheath Color Clear
Wire Style Solid
Conductor Material Copper
Insulation Material modified polyester basecoat and an improved polyam
