Ethernet / Internet Relay Board, Web Ip Snmp For Automation Daenetip1 Daenetip2

US $100.00

Jerusalem, IL, Israel
Jan 29th

Open on mobile:
QR code

Ethernet / Internet Relay Board, WEB IP SNMP for Automation DAEnetIP1 DAEnetIP2 Buy it today for only $98 This is a very Limited Time Offer at this price! So please Do Not Miss Out, make the right decision and Buy It Now! ITEM WILL BE SENT AFTER PAYMENT IS RECEIVED. WHAT YOU RECEIVE: DAEnetIP1-controller DAEnetIP2-controller AC-DC Adapter 220-240v -> 12V DC-cable 2 - OMRON relay board for DAEnetIP2 ALL in workable conditions- as new CONTACT US: If you have any questions about item please do not hesitate to contact us and we will answer your question asap. DAEnetIP1 This is relay board based on DAEnetIP1 ethernet controller with 4 SPDT relay channels. Additionaly it has 8 digital outputs, 8 digital inputs/outputs and 8 analog inputs. Just connect the device into your local network and control it from another computer or android smartphone over the LAN or Internet. You may control it via DAEnetIP1 Manager, command line, browser or Smartphone. We can provide software examples in Java, .NET, Labview, PHP and it can be used for home automation, industrials, sensor monitoring, controlling relay boards or embedding in larger systems. Features: 10/100 Full duplex Ethernet interface (Auto MDIX) Power supply 12VDC / 250mA 4 x SPDT relays OMRON G5LA-1-CF 8 x digital outputs (0-3.3VDC) 8 x analog inputs with 10 bit resolution (0-2.5VDC) with pull-down resistors 8 x configurable digital I/O port (0-3.3VDC) Hardware "Pulse" function for the digital outputs Standart protocols: ARP, IP, ICMP (ping), DHCP Supports snmp v1 (snmpset, snmpget, snmptrap), HTTP (web server with autorization) , TFTP (for firmware upgrade) Port for SNMP (161) can be changed It can be configured with SNMP requests or web browser Integrated WEB server for all functions/parameters access Reset of the digital outputs on incoming/outgoing ping timeout Function "load outputs states from EEPROM on boot" Each I/O line can be named by user via web browser/snmp It can send traps according analog ADC level An analog input may be referred to control a digital output according its input level Onboard temperature sensor Possibility of connection analog sensors to the analog inputs as LM34DZ, LM35DZ, LM335, MCP9700A Denkovi software: DAEnetIP1 Manager 3rd parity software: Command line utility - netsnmp, Android software (by iSwitch LLC, not free but inexpensive) Software examples: .NET, Java, Labview and PHP DAEnetIP2 This is set of IP controler and relay board with 2 SPDT relays. It is for home automation, hobby and commercial projects. It allows you controlling electrical devices via LAN/WAN (Internet). Just connect the device into your local network and control it from another computer or android smartphone over the LAN or Internet. This IP relay board can be controlled from: Configuration utility - DAEnetIP2 Manager, web browser, command line, android smartphone application or Denkovi Relay Manager Software. We can provide also software examples for developers. Features: 10 Mb Ethernet interface with Link/Activity Led Power supply 12VDC or 24VDC - selectable by user during purchase. (No protection against overvoltage and inverse polarity) Maximal current consumption: 150 mA / 12VDC 100 mA / 24VDC 2 SPDT Relay channels. Relays type is selectable by user during purchase: JQC-3FC/T73 (7A / 250VAC, 10A / 125VAC, 12A / 120VAC, 10A / 28VDC) - single relay channel schematic RAS-12-15 (10A / 250VAC, 15A / 120VAC, 15A / 24VDC) - single relay channel schematic RAS-24-15 (10A / 250VAC, 15A / 120VAC, 15A / 24VDC) - single relay channel schematic 8 analog inputs with 10 bit resolution (0-3.3VDC) (no pull-up or pull-down resistors) 16 (2x8) bit configurable digital I/O port (0-3.3VDC) - in this kit one of the 2 ports is reserved for the relay board Dimensions: Relay PCB - 85mm / 37mm / 20mm; DAEnetIP2 - 43mm / 55mm / 15mm Standart protocols: ARP, IP, ICMP (ping), DHCP Supports snmp v1 (snmpset, snmpget, snmptrap), HTTP (integrated web server with autorization) , TFTP (for firmware upgrade) Ports for SNMP (161) and HTTP (80) can be changed Two MAC addresses protection It can be configured with SNMP requests or web browser Reset of the relays on incoming/outgoing ping timeout Function "load outputs(relays) states from EEPROM on boot" Each I/O line can be named by user via web browser It can send traps according analog ADC level Analog Inputs may be referred to control the relay according their level Possibility of connection analog sensors to the analog inputs as LM34DZ, LM35DZ, LM335, MCP9700A Relay PCB parameters: FR4 / 1.5mm / two layers / metallized holes / HAL / white stamp / solder mask / Extra PCB openings for better voltage isolation / Doubled PCB tracks for better voltage isolation Windows/Linux Software by Denkovi - DRM Software, DAEnetIP2 Configuration utility 3rd parity software: Command line utility - netsnmp, Android software (by iSwitch LLC, not free but inexpensive) Software examples: .NET, Java, Labview and PHP - please contact us for download. For detailed user manual - please contact us for download.

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Fully workable with AC-DC 220-240v -> 12V adapter and DC-cable”
