Eu&us Free! 4axis Nema 23 Stepper Motor 290oz-in,2 Phase, 6-leads Cnc Router Kit

US $188.00

Hamburg, Germany, Germany
Jan 29th

Open on mobile:
QR code

Great News! for USA&Germany buyers ,Ship from USA&Germany warehouse, after payment, within 5 daysfor receiving products! No taxes from customs, no damage, better service, please don't hesitate! ONLY 10 Sets Available For Sale ! ! ! If sold out , the price will risen ! and will need to ship from China ! Wish you have a nice shopping here :) This Item includes: 4 PCS Nema 23 Stepper Motors with 290oz-in holding torque, Single Shaft ,57BYGH633, 1 PC 4 Axis Driver Board TB6560 & Cable & Connectors; 1 PC 350W,24VDC Power Supply; 1 PC CD Disk & Mach3 Software for free offering ! http://www.wantmotor.com 1, Stepper Motor Technical Specifications Part No.: 57BYGH633 Frame Size: NEMA23 Step Angle: 1.8 degree Voltage: 3.0V Current: 3.0 A/phase Resistance: 1.0Ohm/phase Inductance: 1.6mH/phase Holding torque: 13.5Kg-cm 270oz-in (For Bipolar connecting, the holding torque is 270oz-in) Rotor inertia: 480 g-cm2 Detent torque: 0.68 kg-cm Number of wire leads: 6 Weight: 2.20lb (1.0 kg) Length: 78mm Black A+ Green A- Red B+ Blue B- 2, 4 Axis Driver Board 1:The maximum 3.5A drive current to a maximum 86 stepper motor drives, more powerful 2:1-16 sub-setting, higher accuracy, smoother operation 3:Overload over-current over-temperature protection, full protection of your computer and peripheral equipment 4:4 files current settings can be set according to the user the actual current requirement 5:Full closed-type optical isolation to protect the user's computer and equipment 6:Professional design, two-stage signal processing, super anti-jamming 7: Bipolar constant current chopper drive motor low-speed non-creeping phenomenon, noise, non-resonant region? 8: Four input control, you can set limit, emergency stop, which is divided into pairs of knives. The definition of 1-PIN 25 of Parallel Interface is described as follows: PIN2 PIN4 PIN1 PIN16 PIN17 PIN7 PIN14 PIN5 PIN6 PIN3 PIN5 PIN8 PIN9 spindle motor X Empower X Dir X Step Y Empower Y Dir Y Step Z Empower Z Dir Z Step C Empower C Dir C Step The definition of 1-PIN15 of Manual Interface is described as follow(Click the image to upper right for the P1 left P15) P1 P2 P3 P4 P5 P6 P7 P8 P9 P10 P11 P12 P13 P14 P15 Z/CEmpty C Step Z Step X Dir X Empty Y Empty Y Dir Z Dir C Dir Spindle Y Step X Step STOP GND 5V/vdd Limit Switch Description Input 1 Input 2 Input 3 Input 4 Corresponding parallel P10 Corresponding parallel P11 Corresponding parallel P12 Corresponding parallel P13 Output Interface Definition: P1 P2 P3 P4 P5 P6 P7 P8 P9 P10 P11 P12 P13 P14 P15 P16 P17 P18 P19 P20 P21 VDD GND XA+ XA- XB+ XB- YA+ YA- YB+ YB- ZA+ ZA- ZB+ ZB- CA+ CA- CB+ CB- MO/V+ GND MO - 3, 350W ,24VDC Power Supply AC input range selected by switch. Protections:short circuit/overload/over voltage/over temperature 100% full load burn-in test Low cost,high reliability 1 year warranty Size: 215*115*50mm Weight:1.08kg Setup,rise,hold up time: 200ms,50ms,20ms/230VAC at full load Our products are mainly used in robotization, Spinning Automatization, Printing, Packing, Medica Machine, Make-up Equipment, Communication, Household Appliance, Water Pump, Milling Machine, Engraver Machine, CNC Routers.. etc automatic equipment of various trades. We ship worldwide! We product all kinds of motors & driver. And we can manufacture products according to our customer's design. Currently we are looking for qualified stocking distributors with competitive price and good discount in United States & Canada for mutually beneficial long-term relationship. We try our best to support our distributors and business partners to develop more market percentage. Please join us, let’s create the glorious future together! You can add my MSN: stone1818@live.com Skpye: Kalyred Wantai Electrical Appliance Co., Ltd http://www.wantmotor.com

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	wantai
Country/Region of Manufacture	Germany
