Extron 404 Grey Architectural Series Interface

US $380

Argyle, Texas, United States
Mar 24th

Open on mobile:
QR code

Unused untested product. Original packaging is slightly damaged.Equipment ships as shown in pictures. Manufacturer's Information: Video Gain Unity (0.7V), 15% with 3dB peaking (0.8V), 30% with 6dB peaking (0.9V) Bandwidth 300 MHz (-3dB) Video input Number/signal type 1: analog RGBHV, RGBS, RGsB Connectors 1: 9-pin male D connector for MBC/LBC cable or buffer Minimum/maximum levels Analog: 0.3V to 1.45V p-p with no offset at unity gain Impedance 75 ohms or Hi Z,: switchable (set to 75 ohms if no local monitor is connected) Horizontal frequency 15 kHz to 150 kHz (optimum 15 kHz to 62 kHz) Vertical frequency 30 Hz to 170 Hz Return loss -30dB @ 5 MHz Video output Number/signal type 1 analog RGBHV, RGBS, RGsB Connectors 6 BNC female Nominal level Analog: 0.7V p-p, 0.8V p-p, or 0.9V p-p (internal jumper-selectable) w/peaking Impedance 75 ohms Return loss -30dB @ 5 MHz Sync Input type Autodetect: RGBHV, RGBS, RGsB (accepts RGsB but does not strip from video) Output type RGBHV: at all times RGBS at all times RGsB only when input is RGsB Input level 2.0V to 5.5V p-p with +0.2VDC offset max. Output level 4.0V to 5.0V p-p Input impedance 10 kohms Output impedance 75 ohms Max propagation delay 50 nS Max rise/fall time 2.5 nS Polarity Positive or negative Audio — RGB 404 (channels 1 and 2), RGB 406 and RGB 408 Gain Unbalanced 0dB, balanced +6dB Response 20 Hz to 20 kHz, ±0.5dB THD + Noise 0.03% @1 kHz, 0.3% @ 20 kHz at rated maximum output drive S/N >90dB at rated maximum output (14dBu), balanced Stereo channel separation >95dB @ 1 kHz to 20 kHz Audio input — RGB 404 Number/signal type 2 stereo, unbalanced;: 1.0Vrms (+4dBu), 20 Hz to 20 kHz Connectors Ch. 1: 2 RCA female jacks Ch. 2 3.5 mm stereo female jack (2 channel), unbalanced;: tip (L), ring (R), sleeve (ground) Impedance >10 kohms unbalanced, DC coupled Maximum level +8.5dBu Audio input — RGB 406 and RGB 408 Number/signal type 1 stereo, unbalanced;: 1.0Vrms (+4dBu), 20 Hz to 20 kHz Connectors 3.5 mm stereo female jack (2 channel), unbalanced; tip (L), ring (R), sleeve (ground) Impedance >10 kohms unbalanced, DC coupled Maximum level +8.5dBu Audio output — RGB 404 (channels 1 and 2) Number/signal type 2 buffered, stereo (2 channel), balanced/unbalanced Connectors 3.5 mm captive screw connector, 5 pole Impedance 50 ohms unbalanced, 100 ohms balanced Gain error ±0.1dB channel to channel Maximum level (600 ohm) +14dBu, balanced at stated %THD+N Audio output — RGB 406 and RGB 408 Number/signal type 1 buffered, stereo (2 channel), balanced/unbalanced Connectors 3.5 mm captive screw connector, 5 pole Impedance 50 ohms, unbalanced, 100 ohms balanced Gain error ±0.1dB channel to channel Maximum level (600 ohm) +14dBu, balanced at stated %THD+N General Power 12 to 24VAC or VDC, 0.25 A, 5 watts, external (Order the power supply separately.) Temperature/humidity Storage -40° to +158°F (-40° to +70°C) / 10% to 90%, non condensing Operating +32° to +122°F (0° to +50°C) / 10% to 90%, non condensing Rack mount No, but wall or furniture mountable Enclosure type Metal

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	Extron
Model	RGB404G
