Extron Vtg-200 Programmable Video Test Generator W/case

US $3800

Albuquerque, New Mexico, United States
May 27th

Open on mobile:
QR code

Extron VTG-200 Programmable Video Test Generator w/Case ITEM DESCRIPTION: Used, good condition. Tested - Works! (Please Note: This item is used and may have marks, scratches, small dents, scuffs or other cosmetic defects as to be expected from a used item. Please see photos.) ACCESSORIES: Power cable and soft case included. No manual, interface cables, or other accessories. Video signal characteristics Dot clock 230 MHz Pixel clock accuracy 0.02 MHz Scan rate accuracy ±2% Frequency range 15 kHz to 127 kHz Rise/fall time <1.2 ns Video output Number/signal type VTG 150 1 RGBHV, RGBS, RGsB, RsGsBs VTG 200 1 RGBHV, RGBS, RGsB, RsGsBs, NTSC/PAL composite video Connectors VTG 150 5 BNC female, (1) 15-pin HD female, (1) 15-pin D female, (1) 9-pin D female VTG 200 5 BNC female, 1 BNC female, (1) 15-pin HD female, (1) 15-pin D female, (1) 13W3 D female, (1) 9-pin D female Rates VTG 150 VGA_UXGA, Apple/Mac/Quadra, TTL, HDTV VTG 200 VGA_UXGA, Apple/Mac/Quadra, Sun/SGI/NeXT/IBM Power PC, TTL, HDTV Maximum level 1V p-p Impedance 75 ohms Return loss <-30dB @ 5 MHz DC offset ±5mV maximum Control/remote — test generator (VTG 200 only) Serial control port RS-232, 9-pin female D connector Baud rate and protocol 9600, 8-bit, 1 stop bit, no parity Serial control pin configurations 2 = TX, 3 = RX, 5 = GND Program control Extron's control program for Windows® Extron's Simple Instruction Set™ _ SIS™ Extron's Advanced Instruction Set™ _ AIS™ General Power 100VAC to 240VAC, 50/60 Hz, 9 watts, VTG 150 external, autoswitchable; to 9.0VDC, 0.6 A VTG 200 internal, autoswitchable Temperature/humidity Storage -40° to +158°F (-40° to +70°C) / 10% to 90%, non-condensing Operating +32° to +122°F (0° to +50°C) / 10% to 90%, non-condensing Rack mount No Enclosure type Metal Enclosure dimensions VTG 150 4.7" H x 4.6" W x 1.7" D 11.9 cm H x 11.7 cm W x: 4.3 cm D (5.5" (14 cm) H includes connectors) VTG 200 6.3" H x 9.0" W x 2.0" D 16.0 cm H x 22.9 cm W x 5.1 cm D (7.0" [17.8 cm] H including connectors.) Product weight VTG 150 1.7 lbs (0.8 kg) VTG 200 3.3 lbs (1.5 kg) Shipping weight VTG 150 4 lbs (1.8 kg) VTG 200 7 lbs (3.2 kg) Vibration ISTA/NSTA 1A in carton (International Safe Transit Association) Listings UL, CUL Compliances — VTG 200 CE, FCC Class B MTBF 30,000 hours Powered by SixBit's eCommerce Solution
