Factory Sealed New Brivo Acs5000-db Door Board, Two Reader Add-on Board

US $159.50

Houston, Texas, United States
Feb 24th

Open on mobile:
QR code

You are bidding on a new factory sealed ASC5000-DB door expansion board manufactured by Brivo Systems, LLC. Below is the description of this item per the manufacture's website. Please contact the manufacture prior to bidding on this item to ensure that this item will address your needs properly. ACS5000-DB DOOR EXPANSION BOARD • The ACS5000-DB expansion board is a flexible expansion board which enables any Brivo access control system to connect to two additional doors to an ACS5000 panel. The panel interfaces with Brivo’s OnAir, Aparato and stand-alone platforms and provides two additional Wiegand reader inputs as well as two general purpose inputs and outputs to the network. • An ACS5000 panel can support any combination of 14 expansion boards providing support for up to 30 doors per controller. • Users can create a custom system by combining door and input/output expansion boards to meet their unique access security needs. As the needs of a security system inevitably grow, this board provides a cost-effective solution without the need for additional controllers. FEATURES & BENEFITS • Only purchase enough boards to meet your security needs – the ACS5000-DB is a cost effective expansion board. • The panel provides two additional general purpose inputs and outputs each as well as two Wiegand reader inputs to an ACS5000 panel so users can customize their system to meet any site specific needs. • 14 boards can connect to a single ACS5000 panel providing control for up to 30 doors from a single panel. • The first board fits within an existing ACS5000 chassis reducing hardware costs and installation times. • The panel is flexible and can interface with any Brivo system be it OnAirSM, Aparato® or ACS OnSite® • The panel is both UL and CE certified. CAPACITIES • Maximum # of Readers - 2 per expansion board • Maximum # of Open Inputs - 4 per expansion board • Maximum # of Open Outputs - 4 per expansion board • Maximum # of expansion boards per ACS-5000 - 14 • Maximum # of expansion boards per chassis - 2 per 5000-EXP and 4 per 5008-EXP REQUIREMENTS System Requirements • The door board must be connected to an ACS-5000 panel Power - 12VDC @ 90 mA idle 400mA peak with all relays engaged (board only) Necessary for Optimal Performance • Temperature 32 to 125 F° (0 to 49 C°) • Humidity 0% – 85% (Non-Condensing) To maintain UL294 Compliance: • Board must be installed and powered by the ACS5000 chassis Supported Devices • Only 14 expansion (ACS5000-DB or ACS5000-IO) boards can connect to a single ACS-5000 panel. Related Products • Item Part Number Description Size (h" x w" x d") • ACS5000-DB Door Expansion Board-ACS-5000-DB Door Expansion Board 3.5" x 11.5" • ACS5000-IO Input/Output Expansion Board-ACS-5000-IO Input/Output Expansion Board 3.5" x 11.5" • ACS5000-EXP Expansion Chassis -ACS-5000-EXP Holds 2 Boards 15" x 15" x 3.75" • ACS5008-EXP Expansion Chassis, Large-ACS-5008-EXP Holds 4 Boards 23.5" x 15" x 3.75" I HAVE SEEN THIS ITEM FOR SALE FOR AS MUCH AS $600.00 EACH. FOR THIS BRAND NEW AND SEALED. GENUINE BRIVO MODEL ACS5000-DB, DOOR BOARD/ DUAL READER EXPANSION BOARD. ITEM INFORMATION OVERVIEW The ACS5000-DB dual reader expansion board provides two additional Wiegand reader inputs to the Brivo ACS5000 series control panels. Each reader node (input) provides (1) form C (SPDT) output relay for lock power switching, (1) dedicated request to exit input, (1) dedicated door position switch input, (2) auxiliary inputs, and (2) auxiliary Form C (SPDT) output relays. Each input point can be programmed for input line supervision and for normally open or normally closed inputs. ACS5000-DB expansion boards; ACS5000-DB Expansion Board must be connected to an ACS5000-E, ACS5000-W/G or ACS5000-S control panel to operate properly. Brivo ACS5000 series control panels support any combination of ACS5000-I/O and ACS5000-DB expansion boards up to a maximum of 14 expansion boards per ACS5000 series control panel and are connected via high speed bus. To maintain UL294 compliance, the ACS5000-DB must be installed and powered by an ACS5000 series chassis. PLEASE VIEW THE PICTURES OF THIS ITEM AND CONTACT ME WITH ANY QUESTIONS.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	ACS5000-DB
MPN	ACS5000-DB
Brand	Brivo Systems, LLC
Type	Access Control
Country/Region of Manufacture	United States
