Five 5 Axis Cnc Router Plans For Marine And Furniture Industries (cad Files Diy)

US $180.00

Losino-Petrovsky, Russian Federation
Jun 11th

Open on mobile:
QR code

We present you a complete and detailed Solidworks assembly in SLDASM format for your DIY project. Here is what the product package includes: 1. Solidworks .sldasm assembly complete with Five axis CNC router design data, structural, mechanical and material information 2. XLS Excell spreadsheet with Bill of Material List calculation. Information included in BOM applies to expensive European components. You can easily source cheaper components from traders here and other suppliers. 3. Sample screenshots of sourced mechanical components, linear motion parts and stepper motors. We recommend using servo drive systems in your build. 4. Gerber files for producing your own PCB of control drives. This information is useful for education purposes, but there are quite a few of available and bundled servo drive systems. These are easy to purchase and install. 5. Short introduction video of the project. 6. Movement calculations of all five axis in MS Excell 7. Protel PCB gerber files to manufacture control electronics and electronic boards Photos of example builds of this machine by our customers can be available per your request. Description of the project Large industrial grade five axis CNC router with effective work envelope of 6 x 1.7 x 1.1 meters for milling & routing foam materials, composite plastics, wood and other materials. Project design has been engineered and rendered in Solidworks. This CNC machine is excellent for drilling, grinding, 3D milling, cutting, milling and other operations in furniture manufacturing and marine industries, also for artistic and special projects. This machine is perfect for processing large blocks of polystyrene and other foam materials for yacht, catamaran and boat hull forms. Approximate cost of materials, necessary to construct and assemble the machine is within 8500 USD, we also produced DIY plans for assembly of the machine that contain all necessary parametric data, five axis movement calculations (XYZ & AB), Protel PCB gerber files of electronics parts, links and screen captures of parts used and purchased. Hierarchy of Solidworks project includes physical parameters and sizes of parts for ordering at machine shops, for example, all pulleys are identified exactly as on the pages of the web shop we purchased them at and indicate pitch and radius data. This project contains ready to order BOM (bill of materials list), also, links to all parts for sourcing at stores in Europe and China. Exhaustive sizes and parts descriptions will allow you to source components like belts, pulleys, gears and guide rails locally or internationally. What information is not included in this project: 1. Step by step instructions on project build 2. Follow up support by our staff 3. Consulting on building the machine 4. Links to web stores of suppliers for sourcing necessary components and electronics 5. Electronic schematics or details of servo/stepper drives, cable routing, connection schematics, etc. Electronic system is your choice and expertise, we only provide bare mechanical system as Solidworks assembly. Specification: Work area: 6000mm x 1700mm x 1100mm. 4-Axis +/- 360 degree rotation. 5-Axis +/- 310 degree rotation. Spindle 800watt,1 KW,1.5KW,3KW. ( Air cooled/Water cooled). 4th- Axis control Nema34. Stepper/Servo Motor. 5th- Axis control Nema34. Stepper/Servo Motor.: Aluminum 6061 T6, Steel, ready components. Very rigid structure design. Suitable for Milling and Router Machines. Files Will be sent to you by Email within 24 hrs of payment confirmation. If you have any questions please contact us via eBay messaging. Please Note: These Plans are digital files only We are very excited to offer you this product, it combines hundreds of professional engineering hours, intellectual property, machine building expertise and good attention to detail as well as stifness & rigidity calculations. We developed this machine in Japan, engineers who worked on this project are professional machine builders. Please follow us here, we are now working on a planer kit of the same nature and we will offer actual hardware by our own Fujikawa design team for metal detecting in water basins in a short while. Note: Please review all information prior to placing your order, we do not offer refunds at this time. Thank you for your kind attention and your future orders, have a great day!
