Fluke 190-204/am/s 4 Channel Lcd Color Scopemeter Oscilloscope With Scc290 Kit,

US $4,375.00

Sewickley, Pennsylvania, United States
Jun 9th

Open on mobile:
QR code

This meter is the full version with complete Scopemeter program and comes with warranty through Fluke. Never been opened or used, all items still in original hardcase, items all contained in original plastic and packaging. The Fluke ScopeMeter 190-204/S combine the highest safety ratings and rugged portability with the high performance of a bench oscilloscope. Designed for plant maintenance engineers and technicians, these tough ScopeMeter test tools go into harsh, dirty, and hazardous industrial conditions to test everything from micro-electronics to power electronics applications. The ScopeMeter 190-204/S is the one test tool you will reach for to tackle just about any troubleshooting task. They include a multimeter, TrendPlot™ and ScopeRecord™ roll paperless recorder modes and hands free operation with Connect-and-View™ triggering, and much more: Four electrically isolated inputs CAT III 1000 V / CAT IV 600 V safety rated 200 MHz bandwidth model 2.5 GS/s Deep memory: 10,000 samples per channel waveform capture so you can zoom in on the details Quad meter measurements via scope BNC inputs Connect-and-View continuous auto-trigger, single shot, pulse width, and video triggering ScopeRecord roll mode, capture waveform sample data for up to 48 hours TrendPlot, trend measurement readings for up to 22 days Advanced automatic measurements, power (Vpwm, VA, W, PF) and time (mAs, V/s, w/s) IP-51 rated for dust and drip proof to withstand harsh environments Isolated USB ports for memory devices and PC connectivity Li-Ion battery for extended operating timespan: up to 7 hours (BP291 included standard) Charge spare battery using optional external battery charger (EBC290) Easy-access battery door to make it easy to swap batteries A handy slot to tether and lock down the oscilloscope while unattended using a standard Kensington® lock Gain Four Times the Diagnostic Power Plus CAT IV Safety Rating The Fluke ScopeMeter 190-204/S portable scope is double-insulated four-channel floating oscilloscopes safety rated for measurements in CAT III 1000V/CAT IV 600V environments. Three-dimensional testing for industrial systems » Inspect input signals, output feedback loops or safety interlocks simultaneously to find a range of problems including: Circuit voltage/current overloading Signal timing measurements and synchronization issues Attenuation/input impedance mismatch Signal fluctuation/drift Three-phase testing for diagnosing VSD, power inverters, and converters » Test for harmonics, transients and loads at the three-phase power input Troubleshoot DC to AC converters for faulty IGBT gates or filter circuits Test PWM output for reflections and transients or voltage unbalance Safely measure from mV to kV Standard probes that cover a wide application range from mV to kV prepare you for anything from micro-electronics to heavy duty medium voltage electrical applications. Independent isolated inputs eliminate the risk of accidental ground short circuits by allowing you to make measurements in mixed circuits with separate ground references. Take on the harshest conditions with the only IP-51-rated Scope on the Market Rugged and shock-proof, all ScopeMeter portable oscilloscopes are built for harsh environments. Their sealed cases protect them from dust, water vapor, drips, humidity and airborne pollutants ensuring reliable accurate performance every time you need them. Built in multimeter to quickly and conveniently perform precise measurements Built-in digital multimeter Fluke 190-204/S 4-channel models incorporate quad meter measurements via the 4-channel scope BNC inputs. Conveniently switch from waveform analysis to precise multimeter measurements using the built in 5000 count digital multimeter. Measurement functions include VDC, VAC, VAC + DC, resistance, continuity and diode test. Measure current and temperature using suitable shunt, probe or adapter with wide range of scaling factors. Work a Full Shift on a Single Charge New high-performance batteries take advantage of Li-ion technology to keep you going strong for up to seven hours. And with the easy-access battery door you can make battery swaps fast. Capture and Share Waveforms Easily with New USB connectivity Two USB ports, electrically isolated from measurement input circuits offer you easy USB connectivity to a PC or USB memory devices. Store unlimited waveform, screen captures or instrument steups to a USB memory device. Connect to a PC USB interface to transfer and archive critical measurement data using FlukeView software for windows. See a Stable Display Instantly with Connect-and-View&trade Triggering Connect-and-View™ automatically sets up correct triggering by recognizing signal patterns. Without touching a button, you get a stable, reliable, and repeatable display of virtually any signal including motor drive and control signals. Expedites measuring several test-points in rapid succession. Record Up to 48 Hours of High-Resolution Waveforms with ScopeRecord™ ScopeRecord memory stores up to 30,000 data points per channel, capturing intermittents and fast glitches. (Two sets of multiple-channel recordings can be stored for later analysis.) Stores events like motion profiles, UPS, power supply, and motor start-ups With the Stop-on-Trigger mode, the ScopeMeter 190-204/S automatically recognizes a power failure and stores the waveform data preceding it With the waveform zoom (up to 100x) you can look at the smallest details, like individual power cycles Record up to 22 days with TrendPlot™ paperless recorder to find intermittent faults Intermittent faults can be caused by bad connections, dust, dirt, corrosion, or simply broken wiring or connectors. Line outages, sags, or starting and stopping a motor can also cause a machine to stop. The TrendPlot function in the Fluke ScopeMeter test tool helps find those faults by: Plotting minimum and maximum peak values and average over time up to 22 days Plotting any combination of voltages, amps, temperature, frequency and phase for all four inputs, all with time and date stamp to pinpoint faults Specifications Bandwidth 200 MHz Number of channels 200 MHz: 4 channels Real-time sample rate 2.5 GS/s Inputs 4 scope plus DMM input Independently floating isolated inputs Up to 1000 V CAT III/600 V CAT IV between inputs, references and ground Timebase range 2 ns - 2 min/div Input sensitivity 2 mV-100 V/div Trigger types Connect-and-View™, Free Run, Single Shot, Edge, Delay, Dual Slope, Video, Video Line, Selectable pulse width, N-Cycle Trigger source Any scope input channel Glitch capture 8 ns Scope measurements Cursor: 7 Automatic: 30 Maximum record length ScopeRecord mode: 30,000 pts Scope mode: 10,000 pts per input Persistence Digital persistence giving analog oscilloscope-like waveform decay Waveform compare Waveform reference with automatic Pass/Fail testing Environmental Specifications Operating temperature 0°C to 40°C Including Batteries 0°C to 50°C Excluding Batteries Storage temperature -20°C to +60°C Operating altitude Up to 2,000 m (6666 ft) for CAT IV 600 V, CAT III 1000 V Up to 3,000 m (10,000 ft) for CAT III 600 V, CAT II 1000 V Safety Specifications Electrical safety 1,000 V CAT III/600V CAT IV (EN61010-1) Mechanical and General Specifications Li-Ion Battery BP291 4800 mAh battery up to 7 hours included standard Included Accessories VPS410 Voltage Probe Sets (one red, one blue, one grey, one green) BC190 Battery Charger/mains Adapter BP291 4800 mAh high capacity Li-ion Battery Handstrap (affixed to instrument) Hangstrap Multi-Language User Manuals on CD-Rom FlukeView ScopeMeter® demo package

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Fluke
Model	Fluke-190-204/AM/S
