Fluke 43B Single Phase Power Quality Analyzer New - open box to check Get control of power problems The Fluke 43 Power Quality Analyzer performs the measurements you need to maintain power systems, troubleshoot power problems and diagnose equipment failures. All in a rugged handheld package. NiMH Battery provides extended operating time of 6.5 hours Combines the most useful capabilities of a power quality analyzer, multimeter and scope Calculates 3-phase power on balanced loads, from a single-phase measurement Trends voltage, current, frequency, power harmonics and captures voltage sags, transients and inrush current Monitoring functions help track intermittent problems and power system performance Records two selectable parameters for up to 16 days 20 measurement memories to save/recall screens and data with cursor readings FlukeView® software can log harmonics and all other readings over time and provides a complete harmonics profile up to the 51st harmonic Measures resistance, diode voltage drop, continuity, and capacitance Users/applications manual and power quality video to help answer tough questions Complete package with voltage probes and 400 A current clamp, FlukeView Software and optically isolated interface cable Harmonics Voltage, current, and power harmonics Up to 51st harmonic Total harmonic distortion (THD) Phase angle of individual harmonics Power Watts, power factor, displacement power factor (cos ?), VA and VAR Voltage and current waveforms Three phase On-screen graphics show you how to set up 3-phase power measurements Sags and swells Measurements are always automatically recorded to instantly show changes over time Use cursors to read time and date of sags and swells Transients Catch voltage transients and waveform distortion down to 40 nS Catch and save up to 40 transients Correlate the cause of transient with time and date stamps Volts/Amperes/Hertz Specifications Input Characteristics Input impedance 1 M?, 20 pF Voltage rating 600V rms, CAT III V/A/Hz Display True-rms voltage (ac + dc) Ranges: 5.000 V, 50.00 V, 500.0 V, 1250 V* Accuracy: ±(1% + 10 counts) True-rms current (ac + dc) Ranges: 50.00 A, 500.0 A, 5.000 kA, 50.00 kA, 1250 kA Accuracy: ±(1% + 10 counts) Frequency Ranges: 10.0 to 15.0 kHz Accuracy: ± ([% of reading] + [counts]): 0.5% + 2 CF Crest factor Ranges: 1.0 - 10.0 Accuracy: ±(5% + 1 count) Power Display Watts, VA, VAR 1-phase and 3-phase,3 conductor balanced loads Ranges: 250 W - 1.56 GW Accuracy: ±(4% + 4 counts) Fundamental Power Accuracy: ± (2 % + 6 counts) Total Power PF Power Factor Range: 0 - 1.0 Accuracy: ±0.04 DPF Displacement Power Factor, Cos .F Range: 0.25 - 0.9 Accuracy: ±0.04 Range: 0.90 - 1.0 Accuracy: ±0.03 H2 Frequency Fundamental Ranges: 40.0 to 70.0 Hz Accuracy: ± ([% of reading] + [counts]): 0.5% + 2 Harmonics Display Voltage, Current, Frequency Ranges: Fundamental to 51st harmonic Accuracy: Fundamental: VA ±(3% + 2 counts) W ±(5% + 2 counts) 2 to 31st harmonic: VA ±(5% +3 counts) W ±(10% +10 counts) 32 to 51st harmonic: VA ±(15% +5 counts) W ±(30% +5 counts) Frequency Fundamental Ranges: 40 Hz to 70 Hz Accuracy: ±0.25 Hz Phase Range: V, A (between Fundamental & Harmonics) Accuracy: ±3? to ±15? Range: W (between Voltage Fundamental & Current Harmonics) Accuracy: ±5? to ±15? K-factor (Current and Power) Range: 1.0 to 30.0 Accuracy: ±10% THD Total Harmonic Distortion Range: 0.00 - 99.99 Accuracy: ±(3% + 8 counts) Sags and Swells Recording times: 4 min to 16 days (selectable) Vrms Actual, Vrms max, min(AC + DC) Ranges: 5.000V, 50.00V, 500.0V, 1250V* Accuracy: Readings ±(2% +10 counts); Cursor readings ± (2% + 12 counts) Arms Actual, Arms max, min (AC + DC) Ranges: 50.00A, 500.0A, 5.000 kA, 50.00 kA Accuracy: ±(2% +10 counts) Transient Capture Minimum pulse width: 40 ns Useful bandwidth input 1: DC to 1 MHz Number of transients: 40 Voltage threshold settings: 20%, 50%, 100%, 200% above or below reference Reference signal: After START, the Vrms and frequency of the signal are measured. From these data a pure sinewave is calculated as reference for threshold setting. Vpeak min, Vpeak max at cursor: 10 V, 25 V, 50 V, 125 V, 250 V, 500 V, 1250 V Accuracy: ±5% of full scale R, C, Diode, Continuity Resistance ranges: 500.0 ?, 5.000 k?, 50.00 k?, 500.0 k?, 5.000 M?, 30.00 M? Resistance accuracy: ±(0.6% + 5 counts) Capacitance ranges: 50.00 nF, 500.0 nF, 5.000 µF, 50.00 µF, 500.0 µF Capacitance accuracy: ±(2% + 10 counts) Diode Ranges: 0 to 3.000 V Diode voltage: Accuracy: ±(2% + 5 counts) Continuity: Beeper on at < 30 ? ± 5 ? Max current: 0.5 mA Temperature: °C or °F Inrush Current Inrush times: 1 s, 5 s, 10 s, 50 s, 100 s, 5 min Current ranges: 1 A, 5 A, 10 A, 50 A, 100 A, 500 A, 1000 A Cursor readings: A peak max at cursor 1 and cursor 2 Accuracy: ±5% of full scale Time between cursors: 4 to 235 pixels (1 pixel = inrush time/250) Accuracy: ±(0.2% + 2 pixels) Temperature (with accessory) Range: -100 °C - 400 °C Accuracy: ±(0.5% + 5 counts) Scope Display Measurements: dc, ac, ac+dc, peak, peak-peak, frequency, duty cycle, phase, pulse width, crest factor Time ranges: 20 ns/div to 60 s/div Max sampling rate: 25 MS/s Bandwidth Voltage channel [1]: 20 MHz at inputs, 1 MHz with TL24 Leads Current channel [2]: DC to 15 kHz at inputs, 10 kHz with i400s Current Clamp Coupling: AC, DC (10 Hz - 3 dB) Vertical sensitivity: 5 mV/div to 500V/div Vertical resolution: 8 bit (256 levels) Record length: 512 samples per channel Base ranges: 60 S/div to 20 nS/div ± (0.4% + 1 pixel) Timebase modes: Normal, roll, single Pre-trigger: Up to 10 divisions Trigger Source: Input 1 or Input 2 or automatic selection Trigger Mode: Automatic Connect-and-View™, Free Run, and Single Shot Connect-and-View™: Advanced automatic triggering that recognizes signal patterns Automatically adjusts triggering, timebase and amplitude and displays stable pictures Memories 20 (screens, settings, data) Recording Recording times: 4 min to 16 days (selectable) Parameters: Choose one or two parameters from one of the groups below: Volts/Amperes/Hertz Power: Watts, VA, VAR, PF, DPF, Frequency Harmonics, THD, Volts (Fund. & Harmonic), Amperes (F&H) Watts(F&H) Frequency (H), %(H) of total, Phase(H), KF Temperature Resistance: Resistance, Diode, Continuity, Capacitance Scope: DC Voltage, DC Current, AC Voltage, AC Current, Frequency, Pulse Width + or -, Phase, Duty cycle + or -, Peak max, Peak min, Peak min-max, Crest Factor Note *Rated EN 61010-1 600 V CAT III CSA Environmental Specifications Operating Temperature 0°C to +50°C Safety Specifications Electrical Safety EN 61010-1 CAT III, 600V. CSA listed Mechanical & General Specifications Size 232 x 115 x 50 mm Weight 1.1 kg Battery Life Rechargeable NiMH pack (charger included), 6.5 hrs extended operating time (continuous) Shock & Vibration Mil 28800E, Type 3, Class III, Style B Case IP51 (dust, drip, waterproof) Voltage and current waveforms True RMS voltage and current Frequency
