Free Ship Lcd Development Kit 9225 2.0" Tft Display Tft Lcd Pcb Adapter Uno R3

US $340

Dongguan City,Guangdong Province, China
Jan 29th

Open on mobile:
QR code

Introduce We have a total of three electronic screen, they are LCD-2000-3916/LCD-2000-9225/LCD-2000-7775. They are single-chip controller, and all of them can display to a maximum of 176-RGB x 220 -dot graphics on 262k-color TFT panel. The chip can be connected to the outside of the microprocessor directly. And accept the 8-bit high speed bus interface and serial peripheral interface. The display data can be stored in the memory for data RAM which is 176x220x18 bits. We provided development kit include: 1, All chip's datasheet 2, Arduino driver and sample code 3, Application notes for Arduino UNO and Arduino Mega2560 4, Source code for STM32 5, Schematic Features ? Drive 2.0-inch TFT screen LCD-2000 ? Display resolution: 176(H)x220(V) ? Display data RAM : 176x220 x18bits=696960bits ? Display mode: Full color mode, 262K-colors, 8-colors ? Pin set: DB0-DB7 is IO port for data transmission, WR/RS/CS/LE/RST/PWM is control pin ? Supports 8-bit micro-controller interface 8080 series ? IO port power supply voltage:1.65-3.5V ? Low power consumption Return & Refund We absolutely stand behind our products. We also offer a 14 day money back guarantee should you be unhappy for any reason whatsoever. We will refund the entire cost of the item upon receipt of the returned item, not including the shipping and insurance charges. Our aim is 100% customer satisfaction!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	INHAOS
Country/Region of Manufacture	China
Model	LCD-2000-9225+TFT LCD PCB Adapter for UNO R3
