Freescale Tower Circuit Board Kinetis Compatible Twr-proto K60 S12g128 S08 Mpc5

US $25.99

  • Federal Way, Washington, United States
  • Jan 29th
Open on mobile:
QR code
  ~~ Freescale Tower Compatible  ~~ Prototype board This board lets you solder all 320 points access points to Freescale Tower!         I was building my project last month and needed to solder wires permanently to access Freescale Tower Elevator’s signals, but there was no solution to do that. Here, I found this solution for my Freescale Tower prototyping. This board has 320 soldering points  for me to solder wires to access all Elevator’s signals. It is compatible to Kinetis, S08, MPC5, S12 and MCF. It has helped me to keep my project on schedule. You can add a small breadboard in its center to wire your own circuits too. This sale contains just one piece of four layer circuit board as the green board shown above. There is no elevator boards (black) included as shown in the last picture above.       Major highlights for Freescale tower compatible circuit board:   1.       Freescale Tower Compatible.   2.       320 points soldering access.   3.       5V or 3V are connected to the elevators.   4.       Four layer printed circuit board.   5.       Good for Kinetis, MPC5, S08, S12 prototypes.   6.       Gold fingers plated with gold for edge connection. 7.       2mm spacing between each soldering point.           THANK YOU FOR VIEWING.
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand Freescale Tower Compatible
MPN Tower Compatible Proto Board for Kinetis
Model Freescale Tower Proto Board
Country/Region of Manufacture United States
