Full Cnc Kit - Cyclone Pcb Factory Mill Router Engraver Wood Aluminum Plexiglass

US $8300

Columbus, Georgia, United States
Jun 24th

Open on mobile:
QR code

Using a CAD program such as gEDA, or KiCAD to generate circuit boards. You can use this machine with Easel at Inventables! All parts needed to build your own CNC mill to make your own PCB's for your projects - hobby or professional. Build templates are included to build this kit to have a work area of 8" wide, 4" long" and 1" high. It can be modified for a longer width and length, up to 12" x 12" simply by increasing smooth and thread rod lengths. It comes with:- All plastic frame parts to build the CNC machine - RAMPS 1.4 with three stepper motor drivers, and Arduino Mega 2560 with GBRL (specific to CNC milling!) with USB cable - Three NMEA-17 stepper motors with 72oz. holding torque. These steppers are made in the USA! NOT CHEAP OVERSEAS units - 8mm threaded and smooth rods - Nuts and bolts for this machine - LM8UU linear bearings x12 - 608ZZ bearings x5 You will need to supply at least the following to build the machine: - 12Vdc, 5 amp power supply (connected to first green removable terminal below D8) - hobby knife - Allen wrench set - 1/8" or 3mm drill bit - drill - CNC machine base (to mount the frame parts to) - CNC machining work surface ( the sacrificial work surface you work gets attached to) - rotary tool or other spindle and milling/engraving bits - limit switches and wiring (optional) You will need a computer capable of running bCNC or other CAM program in order to control/operate the machine Parts are manufactured in Columbus, GA using durable ABS plastic. These parts are thick and heavy duty. The color of parts kits may vary. These *plastic* parts have a 120 day, one time individual part replacement warranty, from the date of sale. Everything else is as-is, where-is. No returns for refund accepted. You will get what has been described in this auction. Parts are made once you purchase the kit, usually ships in 72 business hours from the time of purchase. The images are one of the unit I built for my use from surplus materials in my inventory. This CNC machine has outstanding performance for a build it yourself kit! Build and basic operation instructions are provided in the youtube links below. Link to video showing adapter modification: https://youtu.be/VpVXTYOjrLU Link to construction notes and bill of materials: https://youtu.be/Gfn5Xjb-Wb8
