Gage Cs8500 Board 500 Ms/s A/d Sampling Pci Card

US $350

Salt Lake City, Utah, United States
Jan 29th

Open on mobile:
QR code

CompuScope 8500 description CompuScope 8500 is a single channel, 500 MS/s, 8-bit, waveform digitizer card for the PCI Bus. Recognizing that until very recently, almost all multi-Megahertz data acquisition was done using Digital Storage Oscilloscopes under GPIB control, GaGe has ported all the features of these DSOs onto the CompuScope card. This means that you do not have to rethink the solution in terms of a completely unknown data acquisition card. You can simply develop the data acquisition system as if an oscilloscope were being used, but instead use a CompuScope card to take advantage of its attractive price and performance. Of course, CompuScope cards are much more than just another DSO under GPIB control: • CS8500 features up to 2 billion samples of on-board acquisition memory. • Multi-card Master/Slave systems provide from 1 to 8 channels of simultaneous A/D conversion, something normal DSOs simply cannot do. • Data transfer rates from CompuScope memory to PC memory or extended memory run as high as 80 MB/s for the CS8500 as compared to a few hundred KB/s for GPIB. • CompuScope cards are easier to program, as Software Development Kits are available for C/C#, MATLAB, and LabVIEW. Operation under Visual Basic.NET and LabWindows/CVI is also possible from the C/C# Software Development Kit. • CompuScope cards are installed inside the PCI bus chassis, so there is no external box such as a DSO. • CS8500 cards have standard features such as Multiple Record, which help optimize the use of the on-board memory by stacking data from successive bursts. • You can also write software for a multi-card system in which all the cards are not in a Master/Slave configuration. GaGe drivers support all these multi-card configurations. CompuScope 8500 can sample one analog input at speeds up to 500 MS/s with 8 bit resolution and store the data in the very deep on-board memory. The CompuScope 8500 uses a high-quality flash A/D converter which can digitize at 500 MS/s rate. In other words, a new sample is taken every 2 nanoseconds. An on-board crystal-controlled timing circuit ensures timebase accuracy and long-term thermal stability of CompuScope 8500. 500 MS/s Sampling 8 Bit Resolution Up to 2 GigaSamples On-Board Acquisition Memory PCI Bus Card with Bus Mastering Capability Fast Data Transfer Rate to System RAM 250 MHz Bandwidth 44 dB SNR Up to 8 Cards in a Master/Slave System for up to 8 Simultaneous channels at 500 MS/s Software Development Kits for C/C++, MATLAB, LabVIEW under Windows 98/ME and Windows NT/2000/XP An on-line search shows a used CS8500 card for sale at $3000.00 *** Very slightly used *** *** 8Mb Expansion Memory Card *** *** Excellent Cosmetic Condition ***

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	AD
Country/Region of Manufacture	United States
Model	CS8500
