Gn Nettest Laser Precision Td-1000xa Sm Fiber Otdr Fiberwizard Td1000

US $1300

Toledo, Ohio, United States
Jun 19th

Open on mobile:
QR code

Content on this page requires a newer version of Adobe Flash Player. The Following Items Are Included: GN NetTest TD-1000XA FiberWizard SingleMode OTDR (BC# 20106) Power Meter: 850nm 1310nm 1550nm Interchangeable SC Connector For Power Meter SM OTDR Source: 1310nm 1550nm Interchangeable FC Connector For Source (2) SM SC-FC Fiber Cables (4) Fiber Optic Wipes AC Adapter/Charger Power Cord RS232 PC Interface Cable Hard Copy User Manual Hard Carrying Case BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! This Item Has A Current Calibration! GN NetTest FiberWizard TD-1000XA Fiber Optic SingleMode MINI-OTDR with Built in Optical Power Meter Dynamic Range: 1310 / 1550nm : 33.5 / 34dB Power Meter: - 850nm - 1310nm - 1550nm Includes Hard Carrying Case & Accessories As Listed Above! Working Condition: Excellent Condition: Refurbished Calibrated: Yes Warranty: 90 Day Exchange Warranty GN NetTest TD-1000XA Fiber Wizard OTDR The FiberWizard is an optical time domain reflectometer, designed to provide a complete fiber media test set in one rugged, portable, easy-to-use unit. It has the capability to detect backscattered (reflected) light in optical fibers, measure fiber attenuation, evaluate splice an connector joints, and locate faults. The FiberWizard has fiber test features, instrument functions and performance capabilities similar to mainframe OTDRs, but in a smaller package. Fiber test features include the ability to test singlemode or multimode fiber, run FAS (Fiber Analysis Software), and perform single- and dual-wavelength tests. Instrument functions include flexible data-averaging modes, multiple loss measurement, trace overlay, and data storage capabilities. The instrument has high dynamic range with combined long range and high resolution electronics for FTTH, CATV and LAN applications. Other standard features on the FiberWizard incldue a high-contrast, 7 inch, backlit LCD display, battery or AC operation, and MS-DOSr file format compatibility. Loss test set functions are available on some models. A Visual Fault Locator option is available, also. Specifications: Center Wavelength 1310/1550nm ± 20nm Maximum Spectral Width <20nm Fiber Type Singlemode 9/125µ Distance Range 1.2km; 5km; 10km; 20km; 40km; 82km; 164km Data Resolution 0.313m, 0.625m, 1.25m, 2.5m, 5m, 10m, 20m Distance Accuracy 0.0025% X distance ± distance resolution Vertical Linearity ±0.1 dB/dB to within 8 dB of the 98% noise floor Real Time Display Update 2/second Dynamic Range (Typical) (SNR=1) 1310nm 33.5 dB 1550nm 34 dB Initial Reflective Deadzone (typical) 3m @ 1310nm; 3.5m @ 1550nm Initial Non-Reflective Deadzone (typical) 15m @ 1310nm; 20m @ 1550nm Display 7 inch diagonal (14 X 11.4cm) LCD with backlight Vertical Scale Setting 0.063/0.125/0.25/0.5/1/2/4 dB/div. Horizontal Scale Setting @ 1.2km: .0061 to .2044 km/div @81km: .1022 to 13.0789 km/div. Power Meter 10 dBm to -65 dBm Light Source Modes: CW, 1kHz & 2kHz Wavelength: 1310nm, 1550nm, or 1310/1550nm Power Output: -10 dBm (typical) Stability: 0.2 dB @ 8 hours (@25° C) Visual Fault Locator Range (optional) 630nm Class II Laser Source up to 3km Connector Type: OTDR Universal SPC Connector interface accepts adapters for all singlemode & multimode connector types Connector Type: Power Meter Connector interface accepts adapters for all connector types. Consult factory for details Dimensions & Weight 11.5"H X 8.25"W X 4.5"D (292 X 209 X 114mm) / 9 Lbs. (4.1kg) Power Requirements Power Supply: 90-240VAC @ 44-65Hz, Auto switching Battery Power: Sealed Lead Acide Battery Pack, 8 Hours typical; 2 hours minimum Environmental Operating: Temperature: 0° to 40°C (32° to 104°F), Humidity: 95% RH max. non-condensing, Maximum Altitude: 15,000 feet Storage: Temperature: -20° to 60°C (-4° to 140°F), Humidity: 95% RH max. non-condensing, Maximum Altitude: 50,000 feet Laser Safety CDRH Class 1 (eye safe) Data Storage 3.5 inch, 1.44 MB, High Density, DOS type disk Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! Contact: Test Equipment Store eBay Sales Phone: 1-419-517-6681 Toll Free : 1-800-548-2381 We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. UPS Ground United States USD 0.00 USPS Express Mail International (EMS) Worldwide USD 0.00 We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you ALL MAJOR CREDIT CARDS & PayPal ACCEPTED Powers Your Online Marketplace Grow your business, not your staff with Kyozou eBay Management Software
