GSSI SIR 4000 Base Module Ground Penetrating Radar Stock# 160527D This is an almost brand new GSSI SIR 4000, with every option and in perfect condition. The unit is ready to connect to a radar, with the capability of being used with the latest Digital Antennas. The SIR4000 is the most advanced scanner available, with a number of features not offered on other units. The battery hour lasts almost 6 hours (depending on settings) and their is a SD card and USB connection for quick download of your scans. Don't miss this opportunity to get the most premium concrete scanner available, at almost 30% its $20,300 retail cost. The unit can be tested in our retail store in Pooler, GA, if you would like to examine the unit before you purchase. Included with the sale is the following: -GSSI SIR4000 -Hard Case -Charger/Cable -2 Batteries -SunShade For more information and images, check out our website at: www.GP-Technical.com SPECIFICATIONS: The SIR® 4000 is GSSI’s first high-performance GPR data acquisition system designed to operate with analog and digital antennas. This controller bridges the legacy of our traditional analog antennas with our next-generation of digital offerings. Combined, this allows true versatility and flexibility by supporting a wide range of users, beginner to advanced, in numerous applications. The SIR 4000 offers unique collection modules, including Quick 3D, UtilityScan®, StructureScan™ and Expert Mode for efficient data collection and visualization. It also incorporates advanced display methods and filtering capabilities for ‘in-the-field’ processing and imaging. Fully integrated, the SIR 4000 provides a simple user interface, plug-and-play GPS integration and convenient data transfer options. Typical Uses • Utility designation • Concrete inspection • Mining and geology • Environmental assessment • Archaeology • Forensics Flexible Design • Compatible with all GSSI analog and digital antennas • Several deployment options for in-field accessibility • Convenient file transfer options Integrated System • Windows® 8 based user interface • Ruggedized, high-resolution 10.4” LED display • Plug-and-play GPS capability Deliver Results • Up to 800 KHz transmit rate • 32-bit output data format • 20,000 ns max time range New User Interface Experience SIR 4000 home screen The SIR® 4000 comes with a new user interface offering a better user experience. The startup screen is a very simple interface to navigate, where users launch application specific modules, last used settings, start new projects, or playback data from previous projects. In addition, one can configure the SIR 4000 to personalized settings including language, units, and color themes. Using the knob or soft key features, users can select various menu options easily and efficiently. Improved Data Collection Mode SIR 4000 expert mode in data collection screen The SIR 4000 incorporates many new features, including new display modes and filtering capabilities for in-the-field processing and imaging. Users have the ability to change display gain and filters in real-time while collecting data. Additionally, users can change the scale, add reference marks, and personalize the color display. Filters include hyperbola matching for data migration, surface position tracking, signal floor tracking and adaptive background removal. Redesigned Quick 3D Mode SIR 4000 Quick 3D mode The redesigned Quick 3D mode offers the capability to collect and create stunning 3D data files. Quick 3D displays data as fully rotational three dimensional cube in real-time, allowing for powerful in-field data interpretation. Flexible Design Overall system flexibility - compatible with all GSSI antennas (analog and digital) Several deployment options for in-field accessibility Convenient file transfer options Integrated System Windows® operating system Simple, user-friendly interactive graphic interface Ruggedized, high-resolution 10.4” LED display Plug-and-play GPS capability Internal, 32 GB data storage IP-65 rated Deliver Results Advanced real-time filters Up to 800 KHz transmit rate (200 KHz transmit rate in USA and Canada) 32 bit output data format 20,000 nanosecond max time range Convenient file transfer options 2-year warranty FCC, CE and RSS-220 compliant System Antennas Compatible with all GSSI antennas Number of Channels Records data from 1 single-frequency antenna or 1 dual-frequency antenna Data Storage 32 GB Display Enhanced 10.4" LED display with internal high brightness, Active matrix 1024 x 768 resolution and 32-bit color GPS Data logged internally Display Modes Linescan, Linescan plus O-scope, Wiggle trace Full 3D, 256 color bins are used to represent the amplitude and polarity of the signal Data Acquisition Data Format RADAN® (dzt) Output Data Format 32-bit Scan Interval User-selectable, up to 4000 scans/sec Number of Samples per Scan 256, 512, 1024, 2048, 4096, 8192, 16384 Operating Modes Continuous (time) or survey wheel (distance triggered) or point mode Time Range 0-20,000 nanoseconds full scale, user-selectable Gain: manual adjustment from -42 to +126 dB Number of segments in gain curve is user-selectable from 1 to 8 Standard Real-Time Filters Infinite Impulse Response (IIR) - Low and High Pass, vertical and horizontal Finite Impulse Response (FIR) - Low and High Pass, vertical and horizontal Advanced Real-Time Filters Migration, Surface Position Tracking, Signal Noise Floor Tracking, Adaptive Background Removal Automatic System Setups Storage of an unlimited number of system setup files for different survey conditions and/or antenna deployment configurations Automatic Antenna Recognition Automatic recognition of Smart Antennas to allow maximum compliant transmit rate Languages English, Chinese, Japanese, French Operating Operating Temperature -20°C to 40°C external (14°F to 104°F) Battery Inspired Energy Ni2040ED, 3 hour runtime (battery life dependent on level of display brightness) Transmit Rate Up to 800 KHz (International) US/Canada and CE rates depend on antenna model Input/Output Available Ports Antenna inputs analog and digital (one at a time), DC power input, Serial RS232 (GPS port), Accessory connector, HDMI video output, Ethernet to PC, USB 2.0 port, mini USB Ethernet RJ45 100BT Ethernet USB Host USB host with external keyboard support, USB flash drive support and USB HUB support Mechanical Dimensions 14x10x2.75 in (36x25x7 cm) Weight 10 lbs (4.53 kg) including battery Relative Humidity <95% non-condensing Storage Temperature -40°C to 60°C (-40°F to 140°F) Trade Ins: We offer some of the highest prices on your used test equipment. We do partial trade ins or will buy your used equipment outright. An estimated trade in value will be assessed within 24 hours of receiving a value request. Payment terms: We accept payment prior to shipping by Visa, MasterCard, AMEX, and Paypal (up to $10.000). Businesses and Universities, please call for payment options. Please notify us of method of payment in a timely fashion after the auction has ended. If a buyer has not made any attempt to contact us 7 days after this auction's end time we will assume they are forfeiting the auction and the item will no longer be available to them. International Buyers: We reserve the right to accept or decline international Paypal and credit cards. International shipping is available, but clearing customs will often result in delivery delays. Shipping Terms: Buyer pays for shipping and packaging for this item. International buyers will pay for shipping charges to their country. * Shipping and handling fees are not refundable under any circumstances. In the case of a return, the buyer is responsible for all shipping fees. * Shipping for international buyers will be invoiced separately from the purchased product due to the high expense of shipping charges. * Your phone number is required for shipping purposes, so please provide it with all correspondence. * Please note that calculated shipping is based on UPS. We also reserve the right to ship for the same cost via FedEx or other carriers. Packaging: All items will be packaged with materials necessary to ensure that the equipment will be adequately protected from the shipping process. Feedback: We appreciate Positive feedback. We leave feedback as soon as we get feedback from you. If you have any problems with the sale, please try to resolve it with us before you leave us a Neutral or Negative feedback. Warranty: No warranty is expressed or implied with any unit. All sales include a 3 day right of return (ROR). For any reason, within 72 hours of taking possession of the item, the buyer can return the item for a complete refund minus all shipping costs. Return Policy: You can return the item for any reason within three days. We put great effort into thoroughly documenting each piece of equipment, typically with very detailed pictures and video clips. We strongly encourage you to study these images closely before you commit to purchasing the item. Please call or email us if you have any questions about anything that you are uncertain about. It is critical that you confirm that this item suites your needs within the three day return policy period. Any returns after two weeks will not be entertained, and we will automatically escalate to Ebay. If you choose to open an Ebay return case, and we are forced to accept the return, you are responsible for the following: *Return Shipping and insurance of the item to our Store at the following address: GP-Technical 246 Pooler Parkway Suite E Pooler, GA 31322 (843)694-6535 *A Restocking fee of 10% of the purchase price for every week (after the initial 3 day return period) that the item is in your possession, not to exceed two weeks.
