Haas Cnc Lathe Sl Series Operator/programming Training Manual May 2012 *1132

US $65.00

  • Goddard, Kansas, United States
  • Feb 17th
Open on mobile:
QR code
Haas  CNC Lathe SL Series Operator and Programming  Training Manual Description: This is a 152 page training manual for Haas CNC Lathe SL Series Vertical Turning Center.  It was used in classes offered by Haas Factory Outlet.  Please click on the above pictures to enlarge and view the table of contents and selected pages. This manual was printed in May of 2012. Incudes sections on: Introduction to Basic Lathe Operation The Cartesian Coordinate System Machine Home Position Tool Geometry Work Zero Offset Absolute and Incremental Positioning The Haas CNC Control Control Display Keyboard Introduction Settings Hydraulic Tailstock Operation Haas Lathe Control Tips G Code Alphabetical Address codes Rules of Grouping Codes Advanced Lathe Programming Definitions Within the Format Machine Defaults Linear Movement-Creating Tool Paths Circular Interpolation Commands Manually Programming Tool Nose Compensation External Radius Calculation Types of Calculations Calculating Compensation for "An Angle" on Your Part Taper Calculation Tool Nose Radius Calculation Diagram Miscellaneous G Codes Tool Nose Compensation G Codes Tool Nose Compensation Programming Tool Nose Compensation Concepts Circular Interpolation Exercise With Tool Compensation Canned Cycles and Additional G Codes Tool Nose Compensation In Canned Cycles G71 and G70 Exercise With Tool Nose Compensation M code Detailed Description Publication Date: May 2012 Publication No.: N/A Number of pages: Approx. 152 This manual is in very good condition. It was obtained from an equipment dealer. No grease smudges or fingerprints. Appears to be new. Questions? Email: eugene@fabersurplus.com Phone: 316-210-4079 after 11:00 am Central Time Please leave message if no answer. Ships USPS Priority Free International Customers please contact me first.
“New Old Stock from Dealership”
Country/Region of Manufacture United States
