Ham Radio: An/urm 25f Rf Signal Generator, 10khz ~ 50mhz, Overhauled .

US $960

  • Cornelius, Oregon, United States
  • Jun 1st
Open on mobile:
QR code
                                                For Auction: (1) RF Signal Generator, Military surplus, AN/URM25F: 10Khz ~ 50mhz, ( 9 overlapping bands). Analog tuning, vacuum tube circuitry.  Metered RF output and modulation , calibrated @50mhz @ 100,000uv (-7DBM). Internal  400hz and 1000hz AM tones for internal AM modulation. Internal 1000khz crystal calibrator. Modes: CW, AM. Unit overhauled:  Unit has been totally re-capped including all of the caps in the audio section and the RF section, Some old corroded and missing hardware replaced and a lot of minor repairs. Attenuator checked ( Resistive 12 step attenuator). Output connectors are BNC style. Audio output connector changed to panel BNC.  Power supply unit reworked to include solid state rectifiers and upgraded filter capacitor. Case has 4 bottom "bumpouts" instead of rubber feet.   IEC AC male panel connector installed.  IEC AC cord set included with purchase. Output meter calibrated @ 50mhz @ -7DBM with a usb microprocessor based RF Power Meter. All bands checked for RF ouput. Modulation meter calibrated. Frequency calibration is accomplished at the top and bottom of each band. We do NOT do cross band tracking. Front cover ( no accessories) with new edge gasket, included. ***** Known issue: RF chassis, upper left panel captive screw, the captive nut in the cabinet is missing. **** ***  RF Unit SN: 3068 , FRONT COVER SN: 3068   PS unit SN: 3068  ****** (THIS IS ONE OF THOSE RARE 25F THAT HAVE MATCHING SERIAL NUMBERS)  Photo:  PENDING.    A great analog RF Signal Generator, reasonably priced, very easy to use, ( we recommend a frequency counter for accurate frequency settings),  Terrific for all those old boat anchor receiver repairs you are doing. RF Panel control features are: RF SET Control, Microvolts Control and 6 step resistive attenuator. Variable Modulation control.   ************* We Recommend an external PRECISION attenuator, as the attenuator and RF Metering in these old things is not all that accurate. ***** Shipping is via FED EX , single boxed and insured. Double boxing available.  ALL SALES FINAL: NO GUARANTEES OR WARRANTIES EXPRESSED OR IMPLIED. NO RETURNS. ~~~~~~~~~~~~~~~~~~~~~~~>  http://www.ebay.com/usr/cornelius_connie   <~~~~~~~~~~~~~~  About us and direct contact information.
