Handheld 100mhz 1gs/s 2channels Oscilloscope Scopemeter Multimeter 2in1 Dso1102b

US $446.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

DSO1102B Features: • High Bandwidth 100MHz Oscilloscope,1GS/s sample rate, and 6000 Counts DMM with analog bargraph. • 1M Memory Depth. • High Refresh Rate (2500 frames) • Large 5.6 inch TFT Color LCD Display,High Resolution(640*480), Dual-Window Design --More clear, More Detailed • One-touch automatic setup optimizes the position, range, timebase, and triggering to assure a stable display of virtually any waveform • Easy-to-use pop-up menu with built-in multi-language help system • 23 Automatic Measurements • Waveform Math: Add, Subtract, Multiply, and Divide • Store and recall over • Automatic cursor tracking measurements • XY Mode • Built-in FFT function converts a time-domain signal into its frequency components to measure harmonic content and distortion in systems • Waveform Recorder to capture/replay input waveforms from CH1 and CH2 with a maximum record length of 1000 frames • Pass-Fail function compares a stored waveform to an unknown input • Average Mode for smoothing waveforms • Square Wave Output (2V, 1kHz) for probe adjustment • USB Host/Device 2.0 full-speed interface ,support removeable disk, LAN Optional ,Easy to control by PC or long-distance. • Dimensions (mm):240(L)x165(W)x50(H), be carried easily. • LabviewVBVC Second Design instance. Specifications: Model DSO1102B Oscilloscope mode Bandwidth 100MHz Real-time Sample Rate 1GSa/s Equivalent Sample Rate 25GSa/s Record Length(Sample Points) Single-channel: Maximum 1M; Dual-channel:Maximum 512k SEC/DIV Range 2nS/div-2000S/div (in a 2, 4, 8 sequence) Delay Time Accuracy 500ps Vertical A/D Converter 8-bit resolution VOLTS/DIV Range 2mV/div~5V/div at input BNC Position Range ±50V(5V/div),±40V(2V/div~500mV/div),2V(200mV/div~50mV/div)±400mV(20mV/div~2mV/div) Rise Time at BNC =20ns) CH1,CH2: ±(0.3divxV/div) (within ±4 divisions from center of screen) Holdoff Range 100ns-10s Trigger Type Edge Trigger on the rising or falling edge Pulse Width Trigger (when >,<,=,?) on positive or negative pulses Pulse Width Range: 20ns-10s Video Trigger on an NTSC, PAL, or SECAM standard video signal Line Range: 1-525 (NTSC), 1-625 (PAL/SECAM) Slope Trigger (when >,<,=,?) on a positive or negative slope Set Time: 20ns–10s Overtime from the rising or falling edge Set Time: 20-10s Alternate Internal trigger on edge, pulse width, video or slope Measurement Cursors Manual: The difference between voltage cursors ?V; the difference between time cursors ?T; 1/?T calculated by Hz. Tracing: The voltage and time at a waveform point Automatic Pk-Pk, Max, Min, Mean, Cyc RMS, Frequency, Period, Rise Time, Fall Time, Positive Width, Negative Width Meter Mode Max.Resolution 6,000 Counts DMM Testing Modes Voltage, Current, Resistance, Capacitance,Diode & Continuity Max. Input Voltage AC: 600V, DC: 800V Max. Input Current AC: 10A, DC: 10A Input Impedance 10 M? Display Type Right angle 5.6 16-digit color LCD Resolution 640*480 dots Contrast 16 gears, with the progress bar to show adjustment Interface USB host and USB slave, Lan Optional Power Supply Voltage DC Input:12--17VDC, 1500mA Mechanical Size 245 x 163 x 52 (mm) Weight 1.3KG (exclusive of packing and accessories) Accessories: Probes x2; Test leads x2; Power adapter x1; USB cable x1; Manual x1; Bag x1; Software x1. Note: we'll ship this item via Express mail service to USA, Canada, Australia, New Zealand, Ireland, Austria, Belgium, Denmark, Germany, France, Finland, Luxemburg, Italy, Spain, Malta, Norway, Sweden, Swiss, UK, Japan, Korea, Thailand, Indonesia, Malaysia, Philippine, Singapore. Clients from other countries pls contact with us in advance to confirm the different shipping charges before you bid.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	DSO1102B
Sample Rate	1GSa/s - 1.9GSa/s
MPN	DSO1102B
Number of Channels	2
Type	Digital
Country of Manufacture	China
Bandwidth	100MHz - 349MHz
Country/Region of Manufacture	China
Channels	2
