Hantek1008a Vehicle Usb Daq 8ch Programmable Generator Oscilloscope 2.4msa/s

US $82.68

Shenzhen,China, China
Jan 29th

Open on mobile:
QR code

????? Feature Highly efficient and cost-effective; 8 channels oscilloscope for vehicle testing; 2.4MSa/s real time sampling rate, 12bit vertical resolution; DAQ card function; 8 channels programmable generator which can analog signals of crankshaft, camshaft etc. 1) Oscilloscope 8 channels oscilloscope, 2.4MSa/s real time sampling rate 12 bits vertical resolution, spectrum analysis function 3) Programmable Generator2 8 channels programmable generator Can analog signals of crankshaft, camshaft etc. 3) Others USB 2.0 interface plug and play, and no need extra power supply; More than 20 types of automatic testing function, a similar interface with benchtop oscilloscope, easy to use; Software support: Windows NT, Window 2000, Windows XP, VISTA, Windows 7, Windows 8. Specifications: Model Hantek1008 Vertical System Analog Channel 8 Input Impedance Resistance: 1M? Input Sensitivity 10mV/div to 5V/div Resolution 12 bits Horizontal System Memory Depth 4K Max. Input 400V (DC+AC Peak) Real-Time Sampling Rate 2.4MSa/s Time BaseRange 1ns/div to 20000s/div(1-2-5sequences) Time Base Precision ±50ppm Trigger System Time Base Range 1ns/div to 20000s/div(1-2-5sequences) Time Base Precision ±50ppm Trigger Source CH1, CH2,CH3,CH4, CH5, CH6,CH7,CH8 Trigger Mode Edge X-Y Mode X-Axis Input CH1 Y-Axis Input CH2 Cursors and Measurement Voltage Measurement Vpp, Vamp, Vmax, Vmin, Vtop, Vmid, Vbase,Vavg, Vrms, Vcrms, Preshoot, Overshoot Time Measurement Frequency, Period, Rise Time, Fall Time, Positive Width, Negative Width, Duty Cycle Cursors Measurement Horizontal ,Vertical, Track, Auto Measure Modes Waveform Signal Process +,- , x,?, FFT, Invert Voltage Range 10mV to 5V/div @ x 1 probe 100mV to 50V/div @ x 10 probe 10V to 5000V/div @ x 1000 probe 100V to 50000V/div @ x 10000 probe 200mV to 100V/div @ 20:1 Current Range 100mA to50.0A/div @ CC65(20A) 1000mA to500.0A/div @ CC65(65A) 1A to100.0A/div @ CC650(60A) 1A to200.0A/div @CC1100(100A) 10A to2000.0A/div @CC1100(1100A) FFT Rectangular, Hanning, Hamming, Blackman Window Math Addition, subtraction, multiplication, division Programmable Generator Channel 8 Output Level LVTTL Frequency Range 0-250kHz Interface USB 2.0 Power No need extra power supply Size 185 x 150 x 27 (mm) Weight 0.35kg Package Contents: 1* Hantek 1008A host 1* USB Line 4* alligator clips 4* Connector 1* CD (Manual etc.) Items are only shipped after PAYMENT is received Please check out your ADDRESS carefully when processing order If you haven't received the parcel in 25 days,please allow us 2-3 days for checking undelivered packages before we issue you refund We can't ship to African countries becasuse of shipping company policy. To USA 7-15 days by e-package, others 15-45 days. If you want to send DHL / UPS / TNT/ Fedex please contact me alone to change the price. Accepts payment with PayPal. Via paypal you can use all major credit cards. Items do not ship until payment is recieved in full. If the item is defective, please notify us within 7 days after the receipt of the item. The item shall be return in its original condition, in order to get it refunded or replaced We rely on our reputation and customer satisfaction to succeed,Therefore,your feedback is extremely important to us ,please leave good feedback to us if you get satisfied with our goods and service. We care about our valued customers,and will always try to help you. Please give us the opportunity to resolve any problem.We understand the concerns and frustrations you might have,and will try your best to resolve the issues. Please email us before leaving any negative feedback or opening any dispute on the site.We will help you to resolve the problem Attention! eBay Custom Tax Policy The policy of customs clearance may differ from each country. We are not responsible for any applicable customs charge, taxes and duties. Import duties and taxes are buyer's responsibility. If you have any inquiry for custom clearance, please leave a message. We will mark the price you want to declare after communication. On Jan-31-14 at 08:03:11 PST, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Hantek
Manufacturer	Hantek
Model	1008A
Country/Region of Manufacture	China
Country of Manufacture	China
