Hardinge Bridgeport Gx 480 2007 Cnc Fanuc Vmc ~500 Hours Plus Tool Holders

US $5600

Chicago, Illinois, United States
Nov 1st

Open on mobile:
QR code

Call/Text or email Dan for more info and video 312-848-9514 dan@machinetoolbids.com Hardinge GX480 2007 Machine Type...............Vertical Machining Centers Manufacturer................Hardinge Model...........................GX480 Year..............................2007 Control.........................FANUC oi-MD Location.......................Riggers floor in Georgia Specifications: Axis Travel X-Axis....................................................................18.90” (480mm) Y-Axis....................................................................15.80” (400mm) Z-Axis....................................................................16.90” (430mm) Table surface to spindle gauge distance...............5.91”-22.83” (150-580mm) Positioning Auto Mode (X, Y,Z Axes).......................................36m/min (1,417ipm) Feedrate Range (X, Y, Z Axes)..............................0.004-23.2m/min (0.1-590ipm) Minimum Increment...............................................0.00004” (0.00001mm) Ball Screw Diameter and Pitch (X & Y Axes)........1.26” x 0.63” (32 x 16mm) Ball Screw Diameter and Pitch (X, Y, Z Axes)......1.26” x 0.472” (32 x 12mm) Spindle Speed.......................................................0,000RPM Motor Power Rating CT/30/15/1min.........7.5/10/20HP (5.5/7.5/15kW) Torque (S3-60%)......................................35ft./lbs (47.7Nm)(1500RPM) Retention Force........................................6,375N (1430lbf) Spindle Taper............................................No. 40, BIG PLUS® Tool Holder................................................BT40 Worktable Working Surface....................23.6” x 15.8” (600 x 400mm) Table Load............................661lbs. (300kg) Number of T-Slots.................3 T-Slot Size............................0.551” (14mm) T-Slot Center Dimension.....4.92” (125mm) Automatic Tool Changer Magazine Capacity..........16 Tools Max. Tool Diameter...........5.9” (150mm) Max. Tool Diameter...........3.15” (80mm) Max. Tool Length..............7.48” (190mm) Max. Tool Weight.............15.7lbs. (7kg) Random Tool Change.....4.5 sec. Coolant Facilities Coolant Capacity...........31.7 Gallons (120L) Accuracy Specifications (ISO - 230-2) Positioning....................0.0004” (.010mm) Repeatability.................0.0002” (.005mm) Miscellaneous Power Requirement.......64FLA Electrical Supply............50 or 60 Hz Voltage..........................220 Air Requirement............70 psi (5kg/cm2) Machine Dimensions Length..........................62.01” (1,575mm) Depth...........................83.35” (2,168mm) Height..........................82.20” (2,088mm) Approx. Weight............6,204lbs (2820kg) AI NANO look-ahead for high speed machining Comes with all available manuals, Probe and 20+ tool holders. Vice and Mist Buster not included Looking for reasonable offers I can get you a freight quote anywhere. Call/Text or email Dan for more info and video 312-848-9514 dan@machinetoolbids.com
