Harris / Gssd / Prd Instruments Type 2191b Standing Wave Detector Kit 10mhz - 1g

US $940

Irvine, California, United States
Oct 23rd

Open on mobile:
QR code

Nice Harris / GSSD – PRD Instruments Type 2191B Standing wave Detector Kit. This Kit contains a Common Base Unit P/N# 2219-B (S/N# 537); 900-W50 GR-900 Precision 50-Ohm Termination (S/N# 537); 900-WN (S/N# 537) GR-900 Precision Short; 3304-L (S/N# 165) 10MHz – 100MHz Tuning Unit; 2219-HL (S/N# 161) 10MHz – 100MHz Detector Head; 3304-M (S/N# 537) 100MHz – 1000MHz Tuning Unit; 2219-HH (S/N# 537) 100MHz – 2300MHz Detector Head; 0900-9711 (900-QNJ) GR-900 to Type “N” (Female) Adapter; bag with 4 screws to secure detector head; Storage Suitcase W/ Fitted Foam (Foam is beginning to deteriorate); specification sheet & price list. Items are in good – very good overall physical and cosmetic condition except on the 2219-HL detector head there are 2 Raytheon style knobs for 1/8” diameter control shafts that have cracked caps (plastic caps on 2 knobs cracked – so those 2 knobs should be replaced). As we have not tested these items we must sell them for parts or repairs per eBay protocol. Nice American Made items useful for Antenna work and laboratory measurement on RF equipment, these items are called out for many tests on Military radio systems & equipment. Here is some information from the specification sheet for this equipment: The PRD 2219K Standing Wave Detector is a preferred replacement for slotted lines between 10MHz and 2.3GHz. Two interchangeable detector heads (10-100MHz) and 100-2300MHz) and three interchangeable tuning units are available separately and mount on a common base unit. They provide 5mW sensitivity and less than 1.02 residual VSWR. Frequency Range: Extended to 10MHz to 2300MHz; Sensitivity: Improved to 5mW at 10Mhz-100MHz, 20mW at 100MHz-2300MHz; Eliminates heavy coaxial lines; Interchangeable Calibrated Susceptances; Adapters available with known Reflection Coefficient; Detector, Susceptances and GR adapters available in transit case; Supplied with calibrated short & 50-Ohm termination for impedance measurements; Components available separately; Residual VSWR: 1.05 (MAX.) 10-2000MHz. Nominally Tuneable to 1.02 Nominally 1.06, 2000-2300MHz. This Kit (Suitcase) has been packaged in a 21” X 18” X 11” box that has a total weight of about 19 pounds. Please see the pictures in the ad as they form a part of the description. This description and information is a “best effort” so please bid accordingly. Please note that I am selling this item for PARTS or REPAIRS and as USED, STRICTLY AS-IS. I ship within 3 days of receipt of funds. CALIFORNIA residents pay sales tax. Item will ship upon receipt of guaranteed funds. PayPal Will ONLY be accepted from users with a CONFIRMED ADDRESS * AND * the Item MUST ship to that SAME ADDRESS.
